Specifications
Brand Name :
Zhongqiao Enlightenment
Model Number :
air flotation machine
Certification :
CTI
Place of Origin :
Shandong,China
MOQ :
1set
Price :
1100 USD-2800 USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
60 Set Per Month
Delivery Time :
7 work days
Packaging Details :
container or customized
Technology :
Activated Sludge, Membrane Bioreactor, Trickling Filter, Sequencing Batch Reactor
Chemicalusage :
Coagulants, Disinfectants (e.g., chlorine, ozone)
Operatingtemperaturerange :
5°C to 40°C
Capacity :
Varies (e.g., 1000 m3/day to 100,000 m3/day)
Effluentquality :
Meets local environmental discharge standards
Control :
Manuel
Influenttype :
Domestic, Industrial, Mixed
Voltage :
110V / 220V / 380V
Treatmenttype :
Biological, Chemical, Physical
Operation :
Fully Automatic
Treatment Style :
Dissolved Air Flotation
Maintenancefrequency :
Monthly, Quarterly, Annually
Powerrequirement :
Depends on plant size and technology (e.g., 50 kW to 5000 kW)
Productname :
Wastewater Treatment Plant
Automationlevel :
Manual, Semi-automatic, Fully automatic
Water treatment capacity (m³/d) :
5
Dissolved water volume (m³/h) :
1-2
Total power (kW) :
4.47
Power of foam scraper(kW) :
0.37
Air compressor model :
OTS-1100-40L
Clear water pump model :
40-200A
Specification of dissolved gas tank (mm) :
DN400×1000
Outline dimension (m) :
3.46x1.9×2.1
Equipment deadweight (t) :
1.8
Description

Dissolved air flotation machine, drawings available, suitable for wastewater from farms, slaughterhouses, electroplating, and food processing

Air Flotation Machine

Drawings Dissolved Air Flotation Machine For Wastewater From Farms Slaughterhouses Electroplating

This air flotation machine adopts in-pump pressurized mixing technology, which draws in water and air simultaneously. It produces fine microbubbles with a diameter of 25–40 microns, eliminating the need for a return pump, air compressor, ejector or dissolved air tank, thus greatly simplifying the overall structure.
Drawings Dissolved Air Flotation Machine For Wastewater From Farms Slaughterhouses Electroplating
Equipped with an automatic gas-liquid separation tank, the unit features a self-regulating dissolved air system with stable and reliable performance. The system can be adjusted within one minute and supports frequent start-stop operation without repeated tuning.
The aeration process of this equipment is realized by a gas-liquid mixing pump. After treatment, part of the clarified water is recycled back to the gas-liquid mixing pump. As the pump draws in liquid, a certain negative pressure is formed at the pump inlet, allowing air to be sucked in together with the liquid through the suction port. The air is then fully dissolved into the liquid under the high-speed shearing action of the pump impeller.
Drawings Dissolved Air Flotation Machine For Wastewater From Farms Slaughterhouses Electroplating
By adjusting operating parameters and the gas-liquid mixing ratio, highly dispersed microbubbles can be generated or maximum air entrainment can be achieved. According to different pump models, the air content in the liquid can reach up to 30%.
When this saturated or supersaturated dissolved air water enters the reaction tank and stays for a period of stabilization, it is quickly depressurized through the release device, releasing a large number of dense microbubbles with a diameter of 25–40 microns.
Drawings Dissolved Air Flotation Machine For Wastewater From Farms Slaughterhouses Electroplating
Drawings Dissolved Air Flotation Machine For Wastewater From Farms Slaughterhouses Electroplating
