Our Carbon Steel Flat Plate Integrated Sewage Treatment Equipment is a highly integrated, robust wastewater processing solution engineered for small-to-medium industrial facilities and decentralized wastewater scenarios. Fabricated with premium Q235B carbon steel flat plates, the main tank is reinforced with multi-layer anti-corrosion coatings (epoxy coal tar pitch/glass flake lining) to ensure long-term durability even in harsh industrial environments. The all-in-one design integrates pretreatment, biological treatment (AO/A²O/MBR), sedimentation, disinfection, and sludge concentration into a compact unit, eliminating the need for separate concrete tanks and significantly reducing on-site construction time. It can be installed underground (with top greening) or above ground, offering exceptional flexibility for various project layouts.

1. Pretreatment: Industrial wastewater enters the grid and regulating tank to remove large suspended solids and balance water quantity/quality, reducing the impact load on the subsequent biological system.
2. Biological Treatment: The equipment adopts AO (Anoxic-Oxic), A²O (Anaerobic-Anoxic-Oxic) or AO+MBR flat membrane processes. High-concentration microorganisms decompose organic pollutants, while denitrification and phosphorus removal reactions are completed in different functional zones, with removal rates of COD, BOD₅, NH₃-N, and TP reaching up to 95%, 96%, 92%, and 85% respectively.
3. Sedimentation & Membrane Separation (for MBR models): Sedimentation tank clarifies the mixed liquid; MBR flat membrane modules further filter the effluent to retain fine particles and bacteria, ensuring ultra-clear water quality.
4. Disinfection & Sludge Treatment: UV disinfection or sodium hypochlorite disinfection eliminates pathogenic microorganisms. Concentrated sludge is periodically discharged for safe disposal or resource recovery.
5. Automatic Control: PLC intelligent control system with touch screen and remote monitoring function, realizing automatic operation, fault alarm, and data recording.

1. Durable Carbon Steel Structure: Q235B flat plate welding, anti-corrosion coating inside and outside, design service life ≥ 15 years, higher strength than FRP equipment, suitable for buried installation and long-term outdoor operation.
2. Compact & Space-saving: Integrated modular design, 30% smaller footprint than traditional split processes, easy to transport and hoist, on-site installation can be completed in 3–7 days.
3. Stable & High-quality Effluent: Meet GB 18918-2002 Grade A discharge standard or local stricter industrial wastewater discharge requirements, and can realize reclaimed water reuse for greening, cleaning, etc.
4. Low Operation & Maintenance Cost: Fully automatic operation, minimal manual intervention, low power consumption, and reduced sludge yield (especially for MBR process).
5. Strong Customization Capability: Can be customized according to industrial wastewater characteristics (such as food processing, chemical, pharmaceutical, printing and dyeing) and treatment scale (1–500 m³/d).

• Small and medium-sized industrial parks, food & beverage plants, chemical plants, electroplating plants, textile mills, pharmaceutical factories
• Factories without access to municipal sewage pipes, industrial zones in remote areas
• Temporary construction sites, mining areas, oilfields, and other mobile or decentralized wastewater treatment scenarios
• Upgrade and reconstruction projects of existing wastewater treatment systems

Zhongqiao Enlightenment is a professional manufacturer integrating R&D, production, sales, installation and after-sales service of integrated sewage treatment equipment. Based in Weifang, Shandong, we have a complete production base and professional technical team, providing one-stop industrial wastewater treatment solutions, from customized design, factory prefabrication, on-site installation and commissioning to after-sales maintenance service. We strictly follow international standards to produce high-quality carbon steel flat plate integrated sewage treatment equipment, helping global customers achieve environmental compliance and sustainable development.
