Specifications
Brand Name :
Zoomline
Place of Origin :
henan China
Model Number :
PE-400*600 600*900 900*1200 1200*1500
MOQ :
1
Payment Terms :
T/T
Supply Ability :
Negotiable
Delivery Time :
30-50 days
Packaging Details :
Wooden box or film
Advantages :
Reliable Performance, Easy Maintenance, Low Operating Cost
Warranty :
1 Year
Feeding Capacity :
10-800T/h
Description

Jaw cone Crusher PE-400*600 600*900 900*1200 1200*1500

Product Introduction

The jaw crusher is currently the most commonly used crusher globally. It has advantages such as a large crushing ratio, uniform product particle size, simple structure, and easy maintenance. There are two types: primary crushing and secondary crushing. The maximum compressive strength of the crushed materials can reach 320MPa. The large and medium - sized jaw crushers are among our company's key products. Especially in the design and production of large - scale jaw crushers, our company is at a leading level in China.

Performance Features

This machine features a large crushing ratio, high output, uniform particle size, simple structure, convenient maintenance, and low production cost.
Model Feed in opening size (mm) Max feed size (mm) Discharge opening adjustment range (mm) Capacity (t/h) Rotary speed of eccentric shaft (r/min) Motor power (kw) Total weight (t) Overall dimensions (L×W×H/mm)
PE - 150×250 150×250 125 10 - 40 1 - 3 250 5.5 0.8 720×660×850
PE - 200×300 200×300 180 15 - 50 2 - 6 260 7.5 1.2 910×750×990
PE - 200×350 200×350 180 18 - 70 3 - 10 260 11 1.5 1000×870×990
PE - 250×400 250×400 210 20 - 60 5 - 20 300 18.5 2.8 1300×1090×1270
PE - 400×600 400×600 340 40 - 100 16 - 60 275 30 7 1730×1730×1630
PE - 500×750 500×750 425 50 - 100 40 - 110 275 55 12 1980×2080×1870
PE - 600×900 600×900 500 65 - 160 50 - 180 250 75 17 2190×2206×2300
PE - 750×1060 750×1060 630 80 - 140 110 - 320 250 90 - 110 29 2660×2430×2800
PE - 900×1200 900×1200 750 95 - 165 220 - 450 200 110 - 132 52 3380×2870×3330
PE - 1000×1200 1000×1200 850 195 - 265 315 - 500 200 110 - 132 55 3480×2876×3330
PE - 1200×1500 1200×1500 1020 150 - 300 400 - 800 180 160 - 220 100.9 4200×3300×3500
PEX - 150×750 150×750 120 18 - 48 8 - 25 320 15 3.8 1200×1530×1060
PEX - 250×750 250×750 210 25 - 60 13 - 35 330 30 5.5 1380×1750×1540
PEX - 250×1000 250×1000 210 25 - 60 16 - 52 330 30 7 1560×1950×1390
PEX - 250×1200 250×1200 210 25 - 60 20 - 61 330 37 9.7 2140×1660×1500
PEX - 300×1300 300×1300 250 20 - 90 16 - 105 300 55 15.6 2720×1950×1600
Note: Any change of technical data shall not be advised additionally.
