Microwave Fluidized Bed Roasting 0.05mm To 3mm Particle Fluid Bed Boiler System
Microwave Fluidized Bed Roasting 0.05mm To 3mm Particle Fluid Bed Boiler System
Specifications
Brand Name :
Zoomline
Place of Origin :
henan china
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
Negotiable
Delivery Time :
30-50 days
Packaging Details :
Wooden box or film
Particle Size Range :
0.1-5 Mm
Residence Time :
5-30 Minutes
Scale-Up Potential :
High
Automation Level :
High
Material :
Solid Particles
Environmental Impact :
Low
Maintenance Cost :
Low
Uniformity Of Roasting :
High
Description

Microwave-Enhanced Fluidized Bed Roasting System

The arrangement of bottom air caps maximizes the specific surface area of materials, ensuring full

The microwave-enhanced fluidized bed roasting system is designed for high-activity mineral processing, utilizing a 2.45 GHz microwave array to boost reaction efficiency by 35%. The wear-resistant silicon carbide lining extends its lifespan, and it is particularly effective in processing zinc concentrate for rapid desulfurization. This system is effective with particle sizes ranging from 0.05 to 3 mm.

Key Features:

  • Conical Expansion Structure: Extends gas retention time by 30%, promoting more efficient heat transfer.

  • Gas + Microwave Dual Heating: Flexible heating technology combining traditional gas with microwave power.

  • Real-Time Power Adjustment: Uses advanced technology to match microwave power dynamically during the roasting process.

Core Advantages:

  • High Desulfurization Efficiency: Achieves over 98.5% sulfur removal.

  • Energy Savings: 22% reduction in energy consumption.

  • Coke-Free Operation: The patented fluidizing plate design ensures consistent operation.

  • Model    		 Diameter (mm) Capacity (t/h) Power (kw) Weight (t)
    ZLFT - 0.6m² 900 0.1 - 1.2 5.5 - 7.5 3.5
    ZLFT - 1.1m² 1200 0.3 - 2.7 11 - 15 5.9
    ZLFT - 3m² 2000 1.1 - 3.5 22 - 30 17
    ZLFT - 5m² 2600 3.8 - 7.9 30 - 45 26
    ZLFT - 16m² 4600 15 - 30 90 - 110 55
    ZLFT - 32m² 6400 26 - 60 132 - 180 98
