zinc oxide rotary kiln equipment Adaptable motor, reducer, transmission device

Introduction to zinc oxide rotary kiln equipment

Introduction to zinc oxide:

Zinc oxide is a white or slightly yellow fine powder, and its Chinese name is zinc oxide. Also known as zinc white; zinc oxide powder. It is easily dispersed in rubber and latex. It is a reinforcing agent, activator and vulcanizer for natural rubber and synthetic rubber, and is also a colorant and filler for white rubber.

Introduction to zinc oxide rotary kiln:

The zinc oxide rotary kiln crushes zinc furnace charge and coking coal into particles smaller than 40 mesh, mixes zinc furnace charge and coking coal in a ratio of 1:0.30-0.35 to obtain a mixture, and then makes the mixture into a granular mixture with an effective diameter of 8-15 mm, and finally puts the granular mixture into a rotary kiln for smelting. When it is used to smelt zinc oxide from zinc oxide ore or zinc-containing industrial slag with a zinc content of 15%-25% to produce zinc oxide, it has the advantages of greatly saving coke or coal; the product quality obtained by smelting is good, and the productivity is improved with a small amount of nodules.

Performance characteristics of zinc oxide rotary kiln

A. Adopt the most advanced hydraulic wheel blocking device at home and abroad.

B. Adopt the metering plunger pump with high metering accuracy.

C. Domestic advanced technologies such as high-precision speed regulating valve and contact graphite block sealing device.

D. Easy to operate and reliable to use.

E. Stabilize the thermal system and improve the equipment operation rate.

F. Compared with the equipment of the same specification, the operation rate is increased by 10%, the output is increased by 5%-10%, and the heat consumption is reduced by 15%.

Type	Model	Barrel Diameter (mm)	Barrel length (mm)	Slope (%)	Capacity (t/h)	Speed	Motor Power (kW)	Weight (t)
	YZ1225	1200	25000	4	3	0.35 - 3.55	15	34
	YZ1632	1600	32000	4	3.5	0.53 - 5.25	22	46.82
	YZ1636	1600	36000	4	1.2 - 1.9	0.26 - 2.61	22	51.023
	YZ1828	1800	28000	4	4	0.28 - 2.84	30	59.39
	YZ1845	1800	45000	4	4.5	0.28 - 2.84	30	80
	YZ1939	1900	39000	4	1.6 - 3.4	0.31 - 2.82	37	70.704
	YZ2044	2000	44000	3.5	2.4 - 4	0.22 - 2.26	37	97.135
	YZ2245	2200	45000	3.5	3.2 - 5.3	0.23 - 2.25	45	125.462
	YZ2550	2500	50000	3.5	6.2 - 7.4	0.68 - 1.45	55	179.606
	YZ2555	2500	55000	3.5	7.3 - 9.8	0.79 - 2.38	55	191.203
	YZ2820	2800	20000	4	15 - 18	0.8 - 1.45	75	186.373
	YZ3028	3000	28000	4	18 - 23	0.8 - 1.45	75	180.737
	YZ3060	3000	60000	3.5	16 - 20	0.49 - 2.41	90	272.510
	YZ3226	3200	26000	4	22 - 27	0.8 - 1.45	90	185.107
	YZ3255	3200	55000	3.5	17 - 23	0.1 - 1.52	75	271.673
	YZ3529	3500	29000	4	28 - 40	0.16 - 1.38	110	238.031
	YZ3560	3500	60000	3.5	28 - 40	0.65 - 2.25	125	347.872
	YZ4030	4000	30000	4	52 - 70	0.38 - 3.52	160	415.103
