Cement Industry

• Cement Clinker: The cement rotary kiln is used for calcining cement clinker, enabling the raw materials to undergo a series of physical and chemical changes at high temperatures to form cement clinker with hydraulic properties. The dry-process cement kiln has the advantages of low heat consumption and high output; while the wet-process cement kiln has the characteristics of uniform raw material composition and easy control.

Metallurgical Industry

• Pellets: In the ironmaking process, the rotary kiln is used to produce pellets for blast furnaces. Iron ore fines and other raw materials are made into pellets with certain strength and particle size through roasting, which can improve the grade and metallurgical properties of iron ore and is beneficial to the smooth operation of the blast furnace and the improvement of ironmaking efficiency.
• Alumina: In the aluminum production process, the rotary kiln is used to roast aluminum hydroxide into alumina, providing raw materials for the subsequent aluminum electrolysis production.
• Direct Reduced Iron: Abroad, methods such as the "SL/RN method" and "Krupp method" use a rotary kiln to directly reduce iron ore, reducing the iron oxides in the iron ore into metallic iron and producing direct reduced iron, which can be used as high-quality raw materials for electric arc furnace steelmaking.
• Products of Magnetizing Roasting: For lean iron ore, magnetizing roasting is carried out in a rotary kiln to change the original weak magnetism of the ore into strong magnetism, which is conducive to magnetic separation and improves the recovery rate and grade of iron concentrate.
• Products of Roasting of Other Metals: In non-ferrous and ferrous metallurgy, it can also be used for the oxidation roasting of chromium and nickel iron ore, as well as the roasting of metal ores or concentrates such as tungsten, molybdenum, and vanadium to achieve the purposes of metal extraction, enrichment, and separation.

Chemical Industry

• Soda: The rotary kiln can be used for the production of soda, and sodium carbonate and other soda products are obtained through the calcination treatment of relevant raw materials.
• Phosphate Fertilizer: It is used for calcining phosphate fertilizers, such as the roasting of phosphate ore, which can convert the phosphorus in the phosphate ore into a form that is more easily absorbed by plants and improve the effectiveness of phosphate fertilizers.
• Barium Sulfide: Through the calcination reaction of barium-containing ores and sulfur and other raw materials in a rotary kiln, barium sulfide is produced. Barium sulfide is an important chemical raw material and can be used to manufacture barium salts, pigments, rubber vulcanizing agents, etc.
• Phosphoric Acid: In the 1960s, the United States invented a new process for producing phosphoric acid using a rotary kiln. This method has the advantages of low energy consumption, less electricity consumption, no need for sulfuric acid, and the ability to use medium and low-grade phosphate ores, and has been widely promoted.

Building Materials Industry

• Lime: The lime kiln is used for roasting active lime and lightly burned dolomite for steel plants and ferroalloy plants. Active lime has the characteristics of high reactivity, large porosity, and low bulk density. In the steel smelting process, it can improve the fluidity of the slag, accelerate the reaction between the slag and the molten iron, and improve the quality of steel and production efficiency.
• Ceramsite: The rotary kiln can be used for the production of ceramsite. Using clay, shale, fly ash, etc. as raw materials, ceramsite is made through processes such as batching, ball forming, and roasting. Ceramsite has excellent properties such as light weight, high strength, heat insulation, and sound insulation, and is widely used in building insulation, lightweight aggregate concrete, water treatment filter media, and other fields.
• Refractory Materials: It is used for roasting refractory raw materials such as bauxite, magnesia, and chromite ore, making them have higher refractoriness, strength, and erosion resistance. The made refractory bricks, refractory castables, and other products can be used as the linings of high-temperature kilns, furnaces, and other equipment in the metallurgy, building materials, chemical industry, and other industries, playing the roles of heat insulation, heat preservation, and equipment protection.

Environmental Protection Field

• Products of Hazardous Waste Treatment: The rotary kiln can be used for incinerating hazardous waste, such as waste mineral oil, waste organic solvents, and heavy metal-containing waste. Through high-temperature incineration, the hazardous waste is reduced in quantity and made harmless. The harmful substances in the waste are decomposed and transformed, reducing their harm to the environment. At the same time, the heat generated during the incineration process can be recycled.
• Products of Garbage Incineration: It is used for garbage incineration treatment, incinerating municipal solid waste at high temperatures to reduce the volume and weight of the garbage. The heat energy generated can be used for power generation or heating, realizing the resource utilization of garbage.

• (Type)	(Model)	(Barrel Diameter)(mm)	(Barrel length)(mm)	(Slope)(%)	(Capacity)(t/h)	(Speed)(rpm)	(Motor Power)(kw)	(Weight)(t)
  直筒回转窑 (Sraight tube rotary Kiln)	YZ1225	1200	25000	4	3	0.35 - 3.55	15	34
  直筒回转窑 (Sraight tube rotary Kiln)	YZ1632	1600	32000	4	3.5	0.53 - 5.25	22	46.82
  直筒回转窑 (Sraight tube rotary Kiln)	YZ1636	1600	36000	4	1.2 - 1.9	0.26 - 2.61	22	51.023
  直筒回转窑 (Sraight tube rotary Kiln)	YZ1828	1800	28000	4	4	0.28 - 2.84	30	59.39
  直筒回转窑 (Sraight tube rotary Kiln)	YZ1845	1800	45000	4	4.5	0.28 - 2.84	30	80
  直筒回转窑 (Sraight tube rotary Kiln)	YZ1939	1900	39000	4	1.6 - 3.4	0.31 - 2.82	37	70.704
  直筒回转窑 (Sraight tube rotary Kiln)	YZ2044	2000	44000	3.5	2.4 - 4	0.22 - 2.26	37	97.135
  直筒回转窑 (Sraight tube rotary Kiln)	YZ2245	2200	45000	3.5	3.2 - 5.3	0.23 - 1.25	45	125.462
  直筒回转窑 (Sraight tube rotary Kiln)	YZ2550	2500	50000	3.5	6.2 - 7.4	0.68 - 1.45	55	179.606
  直筒回转窑 (Sraight tube rotary Kiln)	YZ2555	2500	55000	3	7.3 - 9.8	0.79 - 2.38	55	191.203
  直筒回转窑 (Sraight tube rotary Kiln)	YZ2820	2800	20000	4	15 - 18	0.8 - 1.45	75	186.373
  直筒回转窑 (Sraight tube rotary Kiln)	YZ3028	3000	28000	4	18 - 23	0.8 - 1.45	75	180.737
  直筒回转窑 (Sraight tube rotary Kiln)	YZ3060	3000	60000	3.5	16 - 20	0.49 - 2.41	90	272.510
  直筒回转窑 (Sraight tube rotary Kiln)	YZ3226	3200	26000	4	22 - 27	0.8 - 1.45	90	Product tags Send your message to this supplier Message* Email* Phone or WhatsApp* Name Company Please reply me within 24 hours. Yes! I would like your verified suppliers matching service! Send Now Submission successful! 1200mm Metallurgical Cement Rotary Kiln Furnace Chemical Kilns Customization Ask Latest Price Watch Video Product Detail Brand Name : Zoomline Model Number : YZ1225 Place of Origin : china MOQ : 1 Price : Negotiable Payment Terms : T/T, Western Union Contact Supplier video Henan Zoomline Machinery Manufacturing co. Ltd Verified Supplier 1 Years henan Since 2018 Business Type : Distributor/Wholesaler, Exporter, Seller Main Products : Fluidized Bed Roasting, Jaw Cone Crusher, Waste Incinerators Total Annual : 1000000-10000000 Employee Number : 130~150 Certification Level : Verified Supplier Discover similar products Ceramsite Sand Rotary Furnace Calcination 0.35-3.55r/Min Contact Now video 0.5 - 2.47r/Min Pelletizing Rotary Kiln Refractory Kiln High Alumina Bricks Contact Now video Stainless Steel Shell Rotary Kiln 150kg/H - 200kg/H Cement Kiln Refractory Contact Now video Zinc Oxide Rotate Kiln Equipment 440V Rotary Calcination Furnace Transmission Contact Now video 190kg/H Carbon Rotary Kiln Infrared Temperature Sensing Kiln In Cement Plant Contact Now video 190t/H Itanium Dioxide Calcination Rotary Kiln PLC Industrial Rotary Kiln Contact Now Metallurgical 200kg/H Rotary Kiln Electromagnetic Heating Calciner Kiln Contact Now video Coal Gangue Rotating Calcination Kiln 150kg/H Rotary Kiln In Cement Industry Contact Now video Chemical Rotary Kiln Dryer 0.35r/MinDust Removal Rotary Kiln Electric Furnace Contact Now video 3.5t/H 4.5t/H Rotating Kiln Feeding And Discharging Lime Rotary Kiln For Cement Contact Now View More Find Similar Products By Category: Supplier Homepage Products Rotary Kiln MachineU China Products Machinery Building Material Machinery Cement Making Machinery Contact Supplier Message* Email* Phone or WhatsApp* Name Company Submit Requirement Please reply me within 24 hours. Yes! I would like your verified suppliers matching service! Submitted successfully! Your request message has been successfully sent to the supplier. Please keep in touch and they will contact you as soon as possible. OK
