DN15 Electric Central Heating 3 Way Valve PN16 Thermostatic Mixing
DN15 Electric Central Heating 3 Way Valve PN16 Thermostatic Mixing
DN15 Electric Central Heating 3 Way Valve PN16 Thermostatic Mixing
DN15 Electric Central Heating 3 Way Valve PN16 Thermostatic Mixing
Specifications
Brand Name :
Runpaq
Model Number :
1703-DN15
Certification :
CE
Place of Origin :
China
MOQ :
50 pieces
Price :
USD25/piece (>1000pcs) / USD26.5 (50-1000 pcs)
Payment Terms :
L/C, T/T, D/A, D/P, Western Union
Supply Ability :
200000 sets/month
Delivery Time :
15-21 days
Packaging Details :
box + maste carton + pallet
Diameter :
DN15-20 (3 way) , DN8-DN32 (2 way)
Pressure :
PN16 / 1.6 Mpa / 232 psi / 16 bar
Max current at idle :
< 25 mA
Max current at full load :
about 550 mA
Torque at 3.6V :
> 1.8NM
Open close time :
< 8 seconds
Valve body material :
brass, stainless steel SS304, 316
Product name :
flow control ball valve with temperature sensor
Description

automag zone valve, heating ball valve for 3 way zone valve control heating system

Product Description

Our motorized valve body is finely made of brass or stainless steel, its pressure rating is PN16, and life time is more than 100,000 cycles. A diverter valve, is one type of heating ball valve, can be located after the hot side circulator and boiler, or at the end of cold side zone circuit. In case of faulty, you can check whether the valve body is in good status, or stuck. Supposing it's good, you can change the motor head only.

Application

  • HVAC system heating, ventilation, air conditioning
  • Heating system
  • Baseboard/radiant heating
  • Convectors
  • Fan coil units
  • Underfloor heating
  • Unit ventilators
  • VAV reheat

DN15 Electric Central Heating 3 Way Valve PN16 Thermostatic Mixing

Advantages

  • Sturday valve body with reasonable structure design, and best material to be used

DN15 Electric Central Heating 3 Way Valve PN16 Thermostatic Mixing

No Name Material Advantage
1. O-ring

Import

fluoro rubber (green)

 Resistance to high temperature, oil, corrosion, chemicals, Work temp.: —30℃+280℃.Quadruple seals, minimize the risk of leakage.
2. Drainage Drain just in case leakage happens
4 0-ring EPDM (red) Between nut and valve body, extra external leak proof, reduce the possibility of internal leak
8. Ball Brass or SS304 Finely polished, rack nickel plating (not barrel plating), smooth surface, improved torque performance
9. Water proof G Avoid water into housing, seal between valve body and valve housing

DN15 Electric Central Heating 3 Way Valve PN16 Thermostatic Mixing

No Name Material Advantages
5. Wall thickness 2.0mm, PN20
6. Teflon washer Import teflon

1. Import teflon tube, numerical processing to perfectly match with ball surface

2. Minimal deformation, polish surface, wearable
7 0-ring EPDM

1. Good elasticity, as buffer after Teflon washer to improve seal effect

2. Reasonable structure design, ensures perfect holding margin
