Specifications
Brand Name :
ZONCN
Model Number :
T9400-22G
Certification :
CE
Place of Origin :
China
MOQ :
1 PC
Payment Terms :
T/T,Paypal
Supply Ability :
100,000 pcs/month
Delivery Time :
7-30 days
Packaging Details :
inside: box; outside: carton
Type :
frequency inverter
Brand :
ZONCN
Voltage :
380v+/-15%
Power :
22kw/30HP
PID control :
Built-in
control mode :
vector control
application :
motor speed control
MOQ :
1 UNIT
Private logo :
Support
CE :
Yes
Description

Universal Application Inverter 380v 22kw VFD Drives With RS485 Communication

ZONCN is a leading company in the field of industrial automation, with its headquarters located in Shanghai. Since its establishment in 2005, ZONCN has been dedicated to the research, development, production, and sales of inverter and servo products. The company's factory, spanning an area of about 27,000 square meters, is staffed by 1000 employees, among which over 60 are professional technical engineers. With strict quality control, the factory has passed the ISO9001 quality control system, and all products hold CE certification. ZONCN has an extensive domestic and international sales network, boasting over 80 dealers. Their products are exported to more than 50 countries across Asia, Europe, Africa, and America, widely applied in diverse industries such as textile, print, CNC machine, food package, injection machine, fan, pump, air compressor, water treatment, and industrial washing machine.

The ZONCN T9000 series VFD inverters stand out in the market with their remarkable features:

  1. Advanced Control Modes: Support open - loop/closed - loop vector control for both synchronous and asynchronous motors, as well as V/F control with built - in PID. This versatility allows for precise control in various applications. For example, in a textile mill, the open - loop vector control can ensure smooth and accurate speed regulation of the motors driving the spinning machines.
  2. High Torque Output: Capable of providing large torque, it ensures smooth motor starting even under heavy loads. In an industrial scenario like a stone - cutting equipment factory, the high - torque output of the T9000 series VFD inverter enables the motor to start the cutting process smoothly, even when dealing with thick and hard stones.
  3. Powerful Functionality: Suitable for most general - purpose applications. In a food packaging factory, the T9000 series VFD inverter can be used to control the motors of different packaging machines, such as filling machines and sealing machines, meeting the diverse requirements of speed regulation and operation stability.
  4. PG Card Compatibility: Supports multiple types of PG cards, facilitating more accurate speed feedback and control. This is crucial in applications like precision CNC machining, where accurate speed control is essential for high - quality processing.
  5. Compact Structure: Easy to install, saving valuable space in industrial settings. In a crowded factory with limited space for equipment installation, the compact design of the T9000 series VFD inverter makes it convenient to be integrated into the existing machinery layout.

The applications of ZONCN T9000 series VFD inverters are extensive:

  1. Industrial Machinery: In injection molding machines, the T9000 series VFD inverter adjusts the motor speed according to the injection process requirements, improving product quality and production efficiency.
  2. HVAC Systems: For fans and pumps in heating, ventilation, and air - conditioning systems, the VFD inverter can adjust the speed based on the actual load, achieving significant energy savings. For example, in a large commercial building, the fans and pumps can operate at reduced speeds during low - load periods, reducing energy consumption.
  3. Conveyor Systems: Widely used in factories and logistics centers, the T9000 series VFD inverter enables flexible speed control of conveyor belts, adapting to different production and transportation needs. For instance, in an e - commerce warehouse, the conveyor belts can be adjusted to different speeds depending on the volume of packages.

ZONCN T9000 Inverter

Universal Application Inverter 380v 22kw VFD Drives With RS485 Communication

Universal Application Inverter 380v 22kw VFD Drives With RS485 Communication

ZONCN T9000 Inverter Model Input Voltage (V) Rated output power(kW) Rated input current(A) Rated output current(A) Motor Power (KW)
T9200-0R4G 1PH AC 220V±15% 0.4 5.4 2.5 0.4
T9200-0R75G 0.75 7.2 5 0.75
T9200-1R5G 1.5 10 7 1.5
T9200-2R2G 2.2 16 11 2.2
T9200-3R7G 3.7 17 16.5 3.7
T9200-5R5G 5.5 26 25 5.5
T9200-7R5G 7.5 35 32 7.5
T9400-0R4G 3PH AC 380V±15% 0.4 3.4 1.2 0.4
T9400-0R75G 0.75 3.8 2.5 0.75
T9400-1R5G 1.5 5 3.7 1.5
T9400-2R2G 2.2 5.8 5 2.2
T9400-3R7G/5R5P 3.7/5.5 10/15 9/13 3.7/5.5
T9400-5R5G/7R5P 5.5/7.5 15/20 13/17 5.5/7.5
T9400-7R5G/11P 7.5/11 20/26 17/25 7.5/11
T9400-11G/15P 11/15 26/35 25/32 11/15
T9400-15G/18.5P 15/18.5 35/38 32/37 15/18.5
T9400-18.5G/22P 18.5/22 38/46 37/45 18.5/22
T9400-22G/30P 22/30 46/62 45/60 22/30
T9400-30G/37P 30/37 62/76 60/75 30/37
T9400-37G/45P 37/45 76/90 75/90 37/45
T9400-45G/55P 45/55 92/113 90/110 45/55
T9400-55G 55 113 110 55
T9400-75G/90P 75/90 157/180 150/176 75/90
T9400-90G/110P 90/110 180/214 176/210 90/110
T9400-110G/132P 110/132 214/256 210/253 110/132
★Please contact us directly for inverter powers above 110kw

Inverter Specification

Item Description
Basic function Control Mode VF control
Sensorless flux vector control(SVC)
Close-loop vector control(FVC)(Above 3.7kW)
Maximum frequency 0~600Hz
Carrier frequency 0.5kHZ——8kHz
The carrier frequency is automatically adjusted based on the load features
Input frequency resolution Digital setting:0.01Hz
Analog setting: Maximum frequency x 0.025%
Start torque G Type:0.5Hz/150%(SVC)
P Type:0.5Hz/100%
Speed range 1:100 (SVC)
Speed stability accuracy ±0.5%(SVC)
Overload capacity G Type:60s for 150% of the rated current, 3s for 180% of the rated current. P Type:60s for 120% of the rated current, 3s for 150% of the rated current.
Torque boost Auto-boost ;
Customized boost: 0.1%~30.0%
V/F Curve Straight-line V/F curve
Multi-point V/F curve
N-power V/F curve (1.2-power, 1.4-power, 1.6-power, 1.8-power, square)
V/F separation 2 types: complete separation; half separation
Ramp Mode Straight-line ramp.
Four groups of acceleration/deceleration time with the range of 0.00`6500.0s
DC braking DC braking frequency:0.00Hz~Maximum frequency
Braking time:0.0s~36.0s
Braking action current value:0.0%~100.0%
JOG control JOG frequency range:0.00Hz~50.00Hz
JOG acceleration/deceleration time: 0.0s~6500.0s.
Simple PLC,Multiple preset speeds It implements up to 16 speeds via the simple PLC function or combination of terminal states
Onboard PID It realizes process-controlled closed loop control system easily
Auto voltage regulation(AVR) It can keep constant output voltage automatically when the mains voltage
Overvoltage/overcurrent stall control The current and voltage are limited automatically during the running process so as to avoid frequent tripping due to over voltage/over current
Rapid current limit It helps to avoid frequent over current faults of the AC drive.
Torque limit and control It can limit the torque automatically and prevent frequent over current tripping during the running process. Torque control can be
implemented in the FVC mode.
　 Support for multiple PG card Support for differential input PG card, resolver PG card ,rotating transformer PG card
