FQ Series Waterproof Circular Connector Socket – 5 Pin High Reliability Electrical Connection Solution

Product Description

The FQ Series Waterproof Circular Connector Socket is a compact and durable electrical connection solution designed for equipment requiring stable power and signal transmission under demanding operating conditions. Manufactured according to the DZ4Q/RE008-84 standard, the FQ Series features an upgraded waterproof structure, reliable contact performance, and excellent mechanical durability.

This 5-pin socket connector provides a balanced solution between connection capacity and installation space. With a rated current of 10A and rated voltage of 400V, it is suitable for applications requiring dependable electrical connection performance in compact equipment systems.

The connector adopts an advanced squirrel-cage elastic contact structure, replacing traditional wire spring contact designs. This optimized structure maintains stable contact pressure, reduces contact resistance, and improves resistance to vibration and mechanical impact. The gold-plated copper contacts ensure excellent conductivity, corrosion resistance, and long-term electrical stability.

The bayonet quick-locking mechanism allows fast connection and secure positioning, improving installation efficiency. The aluminum alloy shell with anodized surface treatment provides a lightweight yet strong housing, offering additional protection and durability for professional equipment applications.

Product Characteristics

• 5 Pin Compact Connection Design -- Provides efficient power and signal transmission while maintaining a space-saving circular structure.

• High Current Carrying Capability -- Supports up to 10A rated current, suitable for equipment requiring stable electrical power transmission.

• Reliable Contact System -- Gold-plated copper contacts provide excellent conductivity and consistent connection performance.

• Waterproof Protection Structure -- IP67-rated sealing design helps prevent dust and water intrusion, improving equipment reliability.

• Quick Bayonet Connection -- Simple locking operation enables convenient installation and maintenance.

• Durable Aluminum Housing -- Anodized aluminum alloy shell offers good mechanical strength and corrosion resistance.

Technical Specification

Working Principle

The FQ Series socket connector achieves reliable electrical transmission through precision-designed contact terminals. After the plug is inserted and locked through the bayonet mechanism, the elastic contact structure creates stable contact pressure between terminals, ensuring efficient current flow and reducing connection instability caused by vibration or environmental changes.

The sealed housing design protects the internal contact system, helping maintain consistent performance in applications exposed to moisture, dust, and temperature variation.

Application Areas

The FQ Series 5 Pin Waterproof Circular Connector is widely used in:

• Industrial automation equipment

• Electrical control systems

• Power connection systems

• Communication equipment

• Testing and measurement devices

• Electronic instruments

• Professional equipment assemblies

Advantages / Selling Points

Reliable Power and Signal Transmission

The 5-pin configuration combined with 10A current capability provides an effective connection solution for equipment requiring both power supply and signal transmission.

Compact Structure with High Performance

The circular connector design saves installation space while maintaining excellent electrical and mechanical performance.

Enhanced Environmental Protection

The IP67 sealing structure improves reliability in applications affected by dust, moisture, and changing environmental conditions.

Long Service Life

The optimized contact structure and high-quality materials support up to 500 connection cycles, reducing replacement frequency and maintenance costs.

Flexible OEM Support

Customized options are available for connector configuration, cable assembly, labeling, packaging, and other project requirements.

Production Process

• Raw material quality inspection

• Precision machining of components

• Contact stamping and gold plating

• Insulator molding

• Shell surface anodizing treatment

• Connector assembly

• Electrical performance testing

• Waterproof inspection

• Final quality control and packaging

Service

• Technical consultation and product selection support

• Sample testing assistance

• Customized connector solutions

• OEM/ODM manufacturing service

• Quality inspection before delivery

• Export packaging support

FAQ

Q1: What is the main feature of this 5 Pin connector?
A: This model combines a compact 5-pin design with 10A rated current capability, making it suitable for stable power and signal connections.

Q2: Does this connector support outdoor equipment applications?
A: Yes. The IP67 protection rating and wide temperature range allow reliable operation in environments requiring dust and water protection.

Q3: What advantages does the squirrel-cage contact structure provide?
A: It helps maintain stable contact pressure, reduce contact resistance, and improve connection reliability during vibration or repeated use.

Q4: Can you provide customized products?
A: Yes. We offer customization services according to customer requirements, including structure design, cable assembly, and packaging solutions.
