Fused Disconnector
Fused Disconnector
Specifications
Data :
10000
N0. :
10
Unit :
kV rms
Test Item :
Rated short-circuit making current
Description

RGW1-24 Outdoor AC Fuse-Switch Combination Breaker

The RGW1-24 is a high-performance outdoor AC fuse-switch combination breaker, engineered by integrating mature switch production experience with advanced HRC fuse protection technology. Designed for 24kV power systems, it provides reliable, eco-friendly, and long-lasting protection.

Core Advantages

  • Strong arc-extinguishing capability
  • Reliable, long-lifetime performance
  • Compact, space-saving design
  • Environmentally friendly & explosion-proof

Applications

Optimized for 24kV power distribution systems requiring robust protection under no-load conditions.

Technical Specifications

Test Item Unit Data
Rated voltagekV24
Rated currentA200/400/630
Rated frequencyHz50/60
Rated short-time withstand currentkA25
Rated short-circuit durations3
Mechanical lifeTimes10000
Main loop resistanceμΩ≤100
