Lithium Battery Insulation Tape
Lithium Battery Insulation Tape
Specifications
Model Number :
Lithium Battery Special Adhesive Tapes
Application :
Insulation and protection in lithium battery manufacturing
Place of Origin :
CHINA
Packaging Details :
Wooden Case
Payment Terms :
T/T
Brand Name :
ZHIROBO
Width :
0.03-0.05 mm
MOQ :
1 Set
Certification :
ISO Certification
Length :
33-200meters
Description
Lithium Battery Insulation Tape
Product Overview

Lithium Battery Special Adhesive Tapes are professional insulating masking tapes designed specifically for lithium battery manufacturing. This comprehensive series includes polyimide high-temperature silicone tape and PP & PET medium-temperature acrylic tape variants.

The film surface features advanced release treatment with low unwinding force, while offering excellent heat resistance, electrical insulation, and resistance to acid, alkali, organic solvents, and lithium battery electrolyte. These tapes are widely used for insulation and fixing applications in lithium battery circuit boards and positive & negative electrode tabs.

Core Features
  • Low unwinding tension, suitable for automatic tape attaching equipment
  • Outstanding electrical insulation performance to improve battery safety
  • Excellent resistance to electrolyte, acid and alkaline solvents
  • Multiple substrates & colors available (Tan, Army Green, Blue, Multi-color)
  • Two temperature grades: high temperature up to 200℃, medium temperature 130℃
  • Stable peeling force with clean removal and no adhesive residue
Application Scenarios
  • Lithium battery cell edge wrapping
  • Insulation fixation for battery positive & negative tabs
  • Protection for lithium battery circuit boards
  • SMT soldering heat insulation shielding
  • Electronic component high-temperature masking

Lithium Battery Insulation Tape

Product Specifications
Model No. Adhesive System Substrate Color Thickness (mm) Length (m) Temperature Resistance Peeling Force (kg/25mm)
ZX-NY50C Silicone 0.025 PI Tan 0.05 33–200 200℃ 0.3–0.4
ZX-BY30G Acrylic PP Green 0.03 33–200 130℃ 0.4–0.5
ZX-BY45G Acrylic PP Green 0.045 33–200 130℃ 0.5–0.6
ZX-BY30B Acrylic PET Blue 0.03 33–200 130℃ 0.4–0.5
ZX-BY45B Acrylic PET Blue 0.045 33–200 130℃ 0.5–0.6
ZX-NY50P Acrylic PET/PP Multi-color 0.03–0.05 33–200 80℃ 0.6–0.8
Service Advantages for B2B Buyers
  • Custom slitting service for different required widths
  • OEM & ODM available with customized logo on rolls & cartons
  • Stable batch consistency to meet mass production demand of battery factories
  • Free samples provided for performance testing
  • Factory direct supply with competitive wholesale pricing
Frequently Asked Questions
How do you ensure machine quality and stability?

We perform full load testing before delivery, with customer witness onsite or via video. We use proven core components and provide detailed manuals plus remote support for reliable operation.

Can your equipment handle frequent product size changes?

Yes. Our modular design and recipe storage allow quick changeovers (time depends on model and product). We can customize tooling to fit your specific packaging range.

We are new to automation. What support do you offer?

We offer turn-key service: layout planning, training, commissioning, and on-site guidance per contract. Remote diagnostics and field support are available when needed.

What about after-sales and spare parts?

We stock common wear parts for prompt dispatch (logistics permitting). We provide preventive maintenance plans and remote troubleshooting, with on-site service arranged as necessary.
