Specifications
Brand Name :
Zhenglan cable
Model Number :
1kv Cu/PVC/PVC Power Cable LV Power Cable class 5 4x50mm2 IEC60502-1
Certification :
ISO 9001:2015, ISO 14001:2005, OHSAS 18001:2007
Place of Origin :
Henan, China
MOQ :
1000 meters
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
20000m/day
Delivery Time :
15 Working Days
Packaging Details :
Fully wooden drum, steel wooden drum, fully steel drum or customized
Material :
Cu
Insulation :
PVC
Sheath :
PVC
Out Sheath Color :
Black or Customized
Cable Length :
as per requirement
Voltage :
0.6/1kv
Standard :
IEC60502-1
Port :
Qingdao
Description

Applications

  • Can be used universally for connecting the power supply in buildings and industrial facilities.
  • Suitable for energy distribution in power and converter stations.
  • Suitable for use in AC and DC charging infrastructures for electromobility.
  • For fixed installation in water, air, soil and concrete. In the ground, the minimum installation depth without additional, suitable protection is 0.6 m, and at least 0.8 m under roads.
  • Can be used in dry, damp and wet environments.
  • Suitable for medium mechanical stress.
  • Suitable for outdoor use, subject to the temperature range.

Construction

  • Conductor: Solid & stranded copper wire class 5
  • Insulation:PVC Compound
  • Sheath:PVC Compound
  • Sheath Color:White ,Black,Grey
Nominal
Insulation
thickness
Nominal
Sheath thickness
Nominal
Overall diameter
Nominal
Cable weight
Max.Resistance of conductor
at 20ºC
mm mm mm kg/km <=(Ω/km)
Four core PVC Power Cables CU/PVC/PVC
0,7 1,8 20.2 795 1,150


0.6/1kv LV Voltage Copper Power Flexible Cable CU/PVC/PVC Class 5 conductor PVC insulation PVC sheath IEC 60502-1

0.6/1kv LV Voltage Copper Power Flexible Cable CU/PVC/PVC Class 5 conductor PVC insulation PVC sheath IEC 60502-1

0.6/1kv LV Voltage Copper Power Flexible Cable CU/PVC/PVC Class 5 conductor PVC insulation PVC sheath IEC 60502-1

0.6/1kv LV Voltage Copper Power Flexible Cable CU/PVC/PVC Class 5 conductor PVC insulation PVC sheath IEC 60502-1


About zhenglan cable:

Zhenglan Cable Technology CO., Ltd.,formerly known as HENAN Zhengzhou Cable Co., Ltd., is one of the large scale backbone enterprises in China's wire and cable industry. The company's registered capital is about 4 million 6 thousand yuan and its headquarter is located in 49 floor of the South Tower of the Greenland Center of Zhengzhou high railway station (Petronas Twin Towers). The factory is located in the Zhengzhou cable science and Technology Industrial Park of the Wuzhi industrial area. It is a modern industrial park integrating advanced research and development technology and production technology.


Why Choose Zhenglan Cable:

  • OEM/ODM services provided;
  • Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted;
  • Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007;
  • Registered capital of $30 million and factory covers an area of 60,000㎡;
  • Advanced test equipment and procedures, 100% inspection before factory;
  • Enough stocks and the higest efficient shipping time guarranteed;
  • Professional pre-sales and after-sales services provided.


RFQ:

1. Is your company a factory or a trade company?
Factory, more than 20 years in China


2. How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~7 days. You can use your own express account or prepay us if you do not have an account.


3. What are your payment terms?
We normally accept T/T 30% deposit, 70% balance before delivery as the main payment terms, and other payment can also be negotiated. Trade assurance on is also available.


4. What’s the delivery time?
Sample order needs 3~5 days.

Formal order depends on the quantity, usually it needs 15 working days after get your payment.


5. What is your MOQ?
Generally it is 5000m.
