BS5467 1KV 5x70mm2 Aluminum Core XLPE Insulated Steel Wire Armor Low Voltage Power Cable
BS5467 1KV 5x70mm2 Aluminum Core XLPE Insulated Steel Wire Armor Low Voltage Power Cable
Specifications
Description
BS5467 1KV SWA Armored Power Cable - 5x70mm² Aluminum Core
This BS5467 1KV SWA armored power cable features 5 insulated aluminum conductors protected by galvanized steel wire armour. Designed for low-voltage mains electricity supply, it is suitable for underground burial, outdoor, indoor, and cable duct applications where mechanical protection is required.
Construction & Features
  • Conductor: Class 1 solid or Class 2 stranded aluminum - round or sectorial shaped
  • Insulation: Cross-Linked Polyethylene (XLPE)
  • Armour: Steel wire armour (STA)
  • Outer Sheath: Polyvinyl Chloride (PVC)
  • UV-resistant black PVC outer sheath
  • Operating temperature: -15°C to +90°C
Key Advantages
  • Mechanical Protection: Robust protection against cutting, impact, and abrasion
  • Cost-Effective: Aluminum conductors offer a lighter, more economical alternative to copper, especially for large sizes
  • Versatility: Ideal for both indoor and outdoor applications, above or below-ground installation
Technical Specifications
Cable Section Nominal Thickness Insulation (mm) Inner Sheath Thickness (mm) Armour Wire Diameter (mm) Nominal Thickness of Sheath (mm) Approx Overall Diameter (mm) Max. DC-resist Conductor 20℃ (Ω/km)
5x70mm² Phase line: 1.1mm 1.2mm 2.0 2.3 43.6 0.443
BS5467 1KV 5x70mm2 Aluminum Core XLPE Insulated Steel Wire Armor Low Voltage Power Cable BS5467 1KV 5x70mm2 Aluminum Core XLPE Insulated Steel Wire Armor Low Voltage Power Cable
Manufacturer Information
Zhenglan Cable Technology Co., Ltd is a professional cable and wire manufacturer with over 20 years of experience. Our 60,000 square meter factory is located in Wuzhi County, Jiaozuo City, Henan Province, China.
Product Range
  • Overhead transmission line bare conductors (ACSR, AAC, AAAC)
  • 1-35kV overhead transmission line insulated conductors
  • 0.6/1kV, 1.8/3kV PVC/XLPE/PE insulated LV power cables
  • 3.6/6kV to 26/35kV XLPE insulated MV power cables
  • 300/300V to 450/750V control cables and house wires
Frequently Asked Questions
Is your company a factory or a trade company?
We are a factory with more than 20 years of manufacturing experience in China.
How long can I expect to get the sample?
Samples are ready for delivery in 3-7 days after payment confirmation. Delivery takes 3-7 days via express service.
What are your payment terms?
Standard terms: T/T 30% deposit, 70% balance before delivery. Trade assurance and other payment methods available.
What's the delivery time?
Sample orders: 3-5 days. Formal orders: 7-30 days after payment, depending on quantity.
What is your MOQ?
Minimum order quantity is typically 500 meters.
