Copper-Clad Steel Stranded Conductor ASTM B228 Grounding Wire for Industrial Applications
Copper-Clad Steel Stranded Conductor ASTM B228 Grounding Wire for Industrial Applications
Specifications
Description

Product Description

Copper-clad steel (CCS) stranded conductor is a bimetallic composite wire consisting of a high-strength steel core metallurgically bonded with a continuous copper outer layer. Multiple CCS single wires are concentrically stranded to form a flexible, durable conductor engineered for grounding, earthing, and power transmission applications.

Construction

A typical 7-strand CCS conductor features one central wire surrounded by six outer wires in a hexagonal arrangement. The copper cladding (6%~10% of wire diameter per ASTM B227) provides conductivity and corrosion protection, while the steel core delivers mechanical strength — up to 2–3 times that of pure copper.

Parameter

Grade 30 HS/EHS

Grade 40 HS/EHS

Conductivity

30% IACS

40% IACS

Cu Thickness

≥ 6% of dia.

≥ 10% of dia.

Density

8.15 g/cm³

8.24 g/cm³

Stranding

7-wire (1+6) / 19-wire

7-wire (1+6) / 19-wire

Applications

· Power substation and transmission tower grounding grids

· Telecommunication tower and data center earthing systems

· Railway and transit signal bonding and lightning protection

· Renewable energy (solar/wind farm) grounding networks

· Industrial plant equipment grounding and static dissipation


Copper-Clad Steel Stranded Conductor ASTM B228 Grounding Wire for Industrial Applications


Copper-Clad Steel Stranded Conductor ASTM B228 Grounding Wire for Industrial Applications


Support and Services:

Copper Clad Steel technical support and services include:

  • Providing product information and technical support.
  • Assistance with product selection.
  • Guidance with product installation and maintenance.
  • Providing product training.
  • Safety inspections and testing.
  • Repair and replacement services.
  • Warranty services.

Why you choose us?

  • OEM/ODM services provided;
  • Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted;
  • Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007;
  • Registered capital of $30 million and factory covers an area of 60,000㎡;
  • Advanced test equipment and procedures, 100% inspection before factory;
  • Enough stocks and the higest efficient shipping time guarranteed;
  • Professional pre-sales and after-sales services provided.
