BV 450/750V Building Wire 1×10mm² H07V-R IEC60227 Copper PVC Single Core Cable for Fixed Wiring
BV 450/750V Building Wire 1×10mm² H07V-R IEC60227 Copper PVC Single Core Cable for Fixed Wiring
Specifications
Description

Product Overview

Zhenglan Cable Technology Co., Ltd. manufactures BV building wire — a 450/750 V single-core, PVC-insulated, non-sheathed copper cable per Chinese standard GB/T 5023 (equivalent to IEC 60227-3).

The 1×10 mm² size BV wire uses a stranded (Class 2) plain copper conductor with a single-layer PVC insulation, intended for fixed wiring inside buildings, conduits, switchboards and appliance connections where the cable is protected by enclosure. It serves final sub-circuits, distribution-board tails and equipment feeds. Conductors are drawn and annealed for uniform resistance, and insulation is extruded and spark-tested on the line.

Applications

BV standard fixed-wiring cable is used in residential and commercial buildings, control panels, lighting circuits and OEM equipment.

Manufacturing Standards

GB/T 5023, IEC 60227, EN 50525-2-31 / VDE 0281-3, UK BS 6004 (6491X), NF C 32-201

Technical Data — Specific Spec 1×10 mm²

Parameter

China (GB/T 5023)

National type designation

BV 1×10

Rated voltage

450/750 V

Conductor

Cu, Class 2, 10 mm²

Conductor Ø

3.99 mm

Insulation thickness

1.0 mm

Overall Ø

6.0 mm

Weight (approx.)

111 kg/km

DC resistance ≤ 20°C

1.83 Ω/km

Test voltage (AC)

2.5 kV

Max conductor temp

+70 °C

BV 450/750V Building Wire 1×10mm² H07V-R IEC60227 Copper PVC Single Core Cable for Fixed Wiring
BV 450/750V Building Wire 1×10mm² H07V-R IEC60227 Copper PVC Single Core Cable for Fixed Wiring
Factory warehouse images
BV 450/750V Building Wire 1×10mm² H07V-R IEC60227 Copper PVC Single Core Cable for Fixed Wiring BV 450/750V Building Wire 1×10mm² H07V-R IEC60227 Copper PVC Single Core Cable for Fixed Wiring
Frequently Asked Questions
Is your company a factory or a trade company?
We are a factory with over 20 years of manufacturing experience in China.
How long can I expect to get the sample?
After payment of freight charges and confirmation of files, samples are ready for delivery in 3-7 days. Delivery via express takes 3-7 additional days. You can use your own express account or prepay if you don't have an account.
What are your payment terms?
We typically accept T/T with 30% deposit and 70% balance before delivery. Other payment terms can be negotiated, and trade assurance is available.
What's the delivery time?
Sample orders require 3-5 days. Formal order delivery time depends on quantity, typically 7-30 days after payment confirmation.
What is your MOQ?
Our minimum order quantity is generally 1000 meters.
