Specifications
Brand Name :
Zhaoli
Model Number :
D6T30H2S01
Certification :
CE, ROHS, REACH
Place of Origin :
China
MOQ :
2000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10,000pcs per day
Delivery Time :
25-45 days
Packaging Details :
cartons + pallets
Name :
BLDC fan motor
Rated voltage :
12VDC
Stack size :
φ30mm
Bearing :
sleeve bearings
Number of stator slots :
six
Number of magnet poles :
four
Construction :
Outer rotor
Number of phases :
three phase
Rectifying method :
electronices
Control type :
PWM
Output signal :
FG
Packing :
Customized packing
Printing :
Customized printing
Application :
air fryer/oven
Description

Microwave Oven BLDC Motor Flexible Speed Adjustment By PWM Control

  • Operating condition
Rated voltage 12VDC
Operating voltage 10.8~13.2VDC
Rotation direction CCW
Working duty continuous
Operating condition 0℃~120℃, RH 5%~90%
Storage condition -20℃~60℃, RH 5%~90%

  • Motor characteristics
Rated voltage 12VDC
Rated load 15.9mN.m
Rated speed(on load) 1850+/- 5% RPM
Rated power(on load) 5W
Insulation class CL.H
Insulation resistance 10MΩmin. (500VDC)
Dielectric strength 600VAC/1S leakage current <=5mA
Temperature rise <75K
Noise Measured at 50CM from motor rated voltage rated speed, no load under controlled condition, undergrounged noise level is less than 50dBA

Motor Driver and Controller

Input voltage 100~255VAC
Output voltage 12VDC
Output power 5W
Control method PWM
Position detection method FOC
Soft start function After the controller is powered on, the motor is slowly accelerated to the required value after starting.

Drawing:

Microwave Oven Bldc Fan Motor Flexible Speed Adjustment By Pwm ControlMicrowave Oven Bldc Fan Motor Flexible Speed Adjustment By Pwm Control

Microwave Oven Bldc Fan Motor Flexible Speed Adjustment By Pwm Control


Application: Microwave Oven

Microwave Oven Bldc Fan Motor Flexible Speed Adjustment By Pwm Control
