500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
500 - 1000 Sheet/Min Facial Tissue Folding Machine Fully Automatic V Fold Facial Tissue Machine
Specifications
Model Number :
HC200-2800
Machine speed :
500-1000 sheet/min/lane
Delivery Time :
30 working days
Embossing unit :
Steel to rubber,steel to paper,steel to steel(should be ordered)
Place of Origin :
FOSHAN,CHINA
Max.diameter of jumbo roll :
Ф1200mm(other sizes can be ordered)
Brand Name :
ZhaoGuang
Name :
Facial Tissue Folding Machine
Packaging Details :
wooden pallet packing
Payment Terms :
T/T
Bankstand :
2-6 jumbo rolls (should be ordered)
MOQ :
1 SET
Inner diameter of jumbo roll :
Ф76.2mm(other sizes can be ordered)
Description

Fully Automatic V Fold Facial Tissue Folding Machine with auto transfer unit and high quality glue lamination unit for optional

HC 200-2800 Facial Tissue Folding Machine

MODEL 5T 6T 7T 9T 10T 14T
Max. Width of jumbo roll 1050mm 1260mm 1500mm 1900mm 2000mm 2850mm
Slitting knife 5sets in back and front 6sets in back and front 7sets in back and front 9sets in back and front 10sets in back and front 14sets in back and front
Vacuum pump 15kw 18.5kw 18.5kw 22kw 22kw 50kw
Main driving motor powe 5.5kw 5.5kw 7.5kw 7.5kw 11kw 15kw
Machine size 6*2.3*1.9m 6*2.5*1.9m 6*2.8*1.9m 6*3.3*1.9m 6*3.5*1.9m 6*4*1.9m
Machine weight 5500kg 6500kg 7500kg 8300kg 8500kg 9500kg
Machine speed 500-1000 sheet/min/lane
Max.diameter of jumbo roll Ф1200mm(other sizes can be ordered)
Inner diameter of jumbo roll Ф76.2mm(other sizes can be ordered)
Bankstand 2-6 jumbo rolls (should be ordered)
Embossing unit Steel to rubber,steel to paper,steel to steel(should be ordered)
Edge embossing unit Air bag type,bearing pattern(should be ordered)
Air pressure 0.8Mpa(user supplied)
