Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Toilet / JRT / Kitchen Towel Rewinding Machine High Speed Tissue Rewinder With Glue Lamination Unit
Specifications
Model Number :
ZGFJ2600
Running Speed :
200-220 meters/min
Delivery Time :
30 working days
Guarantee :
one year
Supply Ability :
300
Unwinding Unit :
1-5 backstands unit
Packaging Details :
wooden pallet
Place of Origin :
Foshan China
Embossing Unit :
steel to rubber , steel to steel , steel to wool
Payment Terms :
T/T
Voltage :
380V, 50HZ
MOQ :
1 set
Kitchen towel :
Optional for glue lamination unit
Brand Name :
ZhaoGuang
Model :
Toilet rewinding machine
Description
Toilet / JRT / Kitchen Towel Rewinding Machine Production Line With Glue Lamination Unit
Glue Lamination System Kitchen Towel Toilet Tissue Rewinding Machine High Speed 220meter/min
ZGFJ-2600(2900) Fully Automatic Productino Line
Features:
  • High speed:220m/min (With the lamination System :180m/min)
  • Can do toilet .JRT in one machine , the glue lamination systme is for optional
  • MITSUBISHI PLC control makes work steadily
  • MITSUBISHI touch screen setting easy to change parameters
  • Separating motor driving
  • MITSUBISHI servo motor driving discharge rolls
  • Accumulator device
  • 2lanes high speed log saw cutter
MODLE 2600 3000
Max.Jumbo roll width(mm) 2550 2950
Capacity 5 tons/day 7 tons/day
Finished product diameter(mm) Ф70-300
Finished product core inner diameter(mm) Ф35-80
Jumbo roll diameter(mm) ≤Ф1500(other size should be ordered)
Jumbo roll core inner diameter(mm) Ф76.2(other size should be ordered)
Perforating size(mm) 110mm(other size should be ordered,4PCS spiral perforating blade)
Machine speed 22m/min
Parameter setting MITSUBISHI touch screen
PLC control MITSUBISHI PLC
backstand 1-6sets(should be ordered)
Air pressure 0.8Mpa(user supply)
Power 15/25Kw,380V,50Hz(base on the model)
Option
Embossing unit Single,double embossing/steel to steel/steel to rubber/steel to paper(should be ordered)
Backstand 1-6 sets(should be ordered)
Jumbo roll loading Pneumatic loader/elevator(should be ordered)
Lamination unit Point to point or glue for nest(should be ordered)
Core or coreless unit Should be ordered
Core winding machine Should be ordered
Automatic core feeding device 300-600PCS storage(should be ordered)
Edge embossing unit Air bag type(should be ordered)
Calendering unit Steel to steel/steel to rubber(should be ordered)
Accumulator 110-210rolls type(should be ordered)
Log saw cutter 2 lanes log saw cutter(should be ordered)
