Specifications
Model Number :
ZS3220-5-800
Dimension(L*W*H) :
5600x3300x4000mm/Customizable
Core Components :
Hechuan servo motor /High power Italian motor /RV reducer 100C /Xinbao planetary gearbox /Hengda guide rail
Payment Terms :
T/T, L/C
Max Cutting Length :
3200*2000mm Customizable
Voltage :
220v/380v /Customizable
Price :
$30,000 / set
Type :
Stone CNC Bridge Cutting Machine
Supply Ability :
1000 SETS ONE YEAR
Color :
Red/Yellow/Blue/White Customizable
Use :
Granite/Marble/Quartz/Porcelain, etc
MOQ :
1
Delivery Time :
30DAYS
Power(W) :
22kw+750w /Customizable
Packaging Details :
OTHERS/5600*2250*2400mm
Cutting thickness (max) :
300mm/Customizable
Place of Origin :
SHANDONG,CHINA
Key Selling Points :
Easy to Operate/High Safety Level/Remote Monitoring /Long Service Life/Energy saving/High-accuracy /Low Noise Level/High Rigidity/Automatic /Eco-Friendly/Multifunctional/Remote Control /High Productivity/Flexible Manufacturing /Famous brand low voltage com
Warranty :
ONE Year
Certification :
CE
Brand Name :
ZSMART
Weight :
4500 kg
Machinery Test Report :
Not Available
Video outgoing-inspection :
Provided
Description
Product Description
Programming method CAD
Control method CNC
Main motor power 22kw permanent magnet motor
Working voltage 220v/380V/50Hz
Control system ZEUS CNC
Blade size 800mm
X-axis working stroke 3700mm
Y-axis working stroke 2200mm
Z-axis working stroke 600mm
HD Camera Contain
A-axis motor power 750w
Chamfering 0-90°
Machine head 360°free rotation
Desktop lifting 0-85°
RV hollow reducer ED3100 Robot specific
Servo motor Hechuan 1.5kw bus servo motor
Electric device schnider
Cutting thickness 300mm
Working table size 3200*2000mm
Overall size 5600x3300x4000mm
Weight 4500kg
Grantee one year
Control software Weihong 5-axis linkage control software
Beam Cast iron beam
