Specifications

Model NO. :

SRM6

Roller Position :

Special Form

Roller Number :

Universal

Layout :

Tandem

Type :

Cold Rolling Mill

Transport Package :

in Foil

Specification :

Customized

Trademark :

Zegota

Origin :

China

Production Capacity :

5000/Year

MOQ :

Description

Main function: Used for cold rolling strip in the high precision and good quality
Components: Uncoiler, hydraulic coil car and unload car, accumulator,entrance and exit platform, rolling mill, left and right recoiler, joint gear box, hydraulic AGC, bending roil system, driving motor, electric control system, lubrication system etc.

Name	Rolling Mill Specification	Max./Min Roll Diameter Φmm	Roll Body Length mm	Max. Rolling Force (t)	Largest Rolling Torque t.m
cold Rolling Mill	Φ600 Hi 2	650/570	800	244	28
	Φ550 Hi 2	600/500	800	220	18
	Φ450 Hi 2	495/420	700	140	12.2
	Φ400 Hi 2	430/370	650	90	4.28
	Φ350 Hi 2	380/330	600	71	2.4
	Φ320 Hi 2	380/330	600	61	2.2
