Automotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing Instrument
Automotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing Instrument
Automotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing Instrument
Automotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing Instrument
Automotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing Instrument
Automotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing Instrument
Specifications
Abrasion Weights :
300 g, 400 g, 500 g, 600 g, 700 g, 750 g, 800 g, 900 g, 1100 g (one of each)
Supply Ability :
9999 units per day
Scraper Blade :
Per ISO 6722, JB/T 8139, JASO D 611, DIN 72551, VW 60306
Certification :
CE, CO
Abrasion Length :
15.5 mm
Price :
980USD
Packaging Details :
wooden box
Scraping Speed :
10 ~ 60 cycles/min (adjustable; one back-and-forth movement = one cycle)
Payment Terms :
T/T,Alipay,Paypal
Scraper Blade Diameter :
0.125 mm
Place of Origin :
China
Scraper Head Stroke :
10 ~ 20 mm (adjustable)
MOQ :
1 unit
Auto-Stop Function :
Machine automatically stops when the scratch needle wears through the insulation and contacts the conductor
Delivery Time :
7 working days
Scratch Needle :
Per QC/T730 standard; diameter 0.45 mm; material conforms to GB/T 4358
Brand Name :
ZEALTAL
Description

Features of Automotive Wire Scrape-Abrasion Tester

This machine is designed to conduct simulated transport testing on products such as toys, electronics, household goods, gift ceramics, and packaging, and complies with US and European transport standards.


Automotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing Instrument

Specifications of Automotive Wire Scrape-Abrasion Tester

Parameter Specification
Scratch Needle Per QC/T730 standard; diameter 0.45 mm; material conforms to GB/T 4358
Scraper Blade Per ISO 6722, JB/T 8139, JASO D 611, DIN 72551, VW 60306
Scraper Blade Diameter 0.125 mm
Scraper Head Stroke 10 ~ 20 mm (adjustable)
Abrasion Length 15.5 mm
Scraping Speed 10 ~ 60 cycles/min (adjustable; one back-and-forth movement = one cycle)
Abrasion Weights 300 g, 400 g, 500 g, 600 g, 700 g, 750 g, 800 g, 900 g, 1100 g (one of each)
Auto-Stop Function Machine automatically stops when the scratch needle wears through the insulation and contacts the conductor

Why Choose Us?

One-Stop Shopping

Sourcing from multiple suppliers wastes your time and cost. As a comprehensive factory supplier of instruments, equipment and tools, we integrate self-produced machines and cooperative brand products. Rich product lines with competitive factory prices help you finish all procurement in one place.

Customer-oriented Service

Our technical team provides full training for equipment installation, debugging and operation. Training options include factory training in China or on-site training at your premises, with transparent cost quotation.

24/7 Online Technical Support

We support instant message, live video and remote operation guidance to deal with your equipment questions efficiently. Free permanent online after-sales support is always ready for you.

Full Quality Warranty

1-year standard free warranty: free repair and spare parts replacement for quality defects (shipping cost excluded).

Order Process

Automotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing Instrument

Ways of Payment

T/T, PAYPAL, WESTERN UNION, ALIPAY

Shipment Solution

1. All quotations are based on EXW terms. We can also provide FOB, CIF, DAP and DDP shipping solutions as per your logistics demands.

2. If you have your own designated freight forwarder, we can arrange delivery of goods to your forwarder’s warehouse free of charge.

3. Multiple reliable shipping channels are available for your choice: DHL, FEDEX, UPS, Sea Shipping and Air Shipping. We will match the most cost-effective transport plan according to your delivery time and budget.

Automotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing InstrumentAutomotive Wire Scrape-Abrasion Tester / Insulation Surface Scrape Tester / Wire and Cable Repeated Abrasion Testing Instrument

FAQ

Do you have your own factory? Yes, we are a manufacturer with complete QC inspection standards.
How long is your product warranty? 1-year free warranty.
Do you support OEM & ODM customization? Yes, we accept customized logo, packaging and product parameters.
What payment methods do you accept? We support T/T and other mainstream international payments.
Can I place a small trial order first?

Small trial orders are welcome before bulk cooperation.
