Solar Power LED Q235B Galvanised Street Light Pole For Public Security CCTV
Solar Power LED Q235B Galvanised Street Light Pole For Public Security CCTV
Solar Power LED Q235B Galvanised Street Light Pole For Public Security CCTV
Solar Power LED Q235B Galvanised Street Light Pole For Public Security CCTV
Specifications
Brand Name :
GUANGXIN
Model Number :
GX-1311
Certification :
ISO9001
Place of Origin :
Guangzhou, China
MOQ :
100pcs
Price :
USD40-80 per piece
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
2000 sets per month
Delivery Time :
20-30 days
Packaging Details :
air bubble sheet package
Name :
Solar Power LED Light Pole with Galvanized Steel Material Q235B
Surface Finish :
Hot dip galvanization plus powder coating(optional)
Galvanization Standard :
ISO 1461 2009, ASTM A123
Color :
Grey Color Painting
Welding Method :
CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
Pole Shape :
conical, tapered, octangular, polygonal, round etc.
Arms :
1 arms or customized ODM
Welding Standard :
AWS D1.1
Grade of bolts and Nuts :
Grade 4.8, 6.8, 8.8
Applications :
Traffic monitor, public security CCTV, parking lotsurveillance etc.
Transportation :
by Sea to clients destination port
Description

Solar Power LED Light Pole with Galvanized Steel Material Q235B

Specification:

Descriptions Steel poles for mounting lights, CCTV camera, guideboards, billboards etc. Double Arm Street Light Pole
Material Low carbon weldable structural steel
Grade GB Q235, Q345, BS4360, ASTM A36 etc.
Yield Strength 235-355MPa
Height 5m to 12m or other specified height
Thickness 4mm to 15mm, depending on height of pole.
Pole Shape Conical/tapered, straight round/cylindrical, square or rectangular, polygonal etc.
Diameter or Dimensions Subject to height of pole and required mechanical properties.
Design Single, dual or multiple straight or curved arms and brackets
Surface Finish Hot dip galvanization plus powder or PVDF coating (optional)
Galvanization 65-100 Microns
Coating 35-80 Microns
Color Silver, grey, black, white, blue, yellow etc.
Applications Roadways, streets, highways, stadiums, public sqaures, airports, railway stations, communities, parking lots, gardens etc.



Solar Power LED Q235B Galvanised Street Light Pole For Public Security CCTV
Hot-DIP Galvanized Steel 6m Outdoor Street Light Poles

Data details:

Height: 8m

Thickness: 3.5mm

Diameter: 80mm/180mm

Material: Steel Q235

Hot-dip galvanizing: 80um

Plastic Spraying Layer: 100um

Flange Plate: 280mm*280*16mm

Lumbar Type Hole: 24mm*50mm

Lamp Arm: 60mm*3mm*1.5m

Solar Panel Support: 20mm*30mm*1.5mm

Performance Standard


Besides conforms to the drawing and design, the materials and fabrication of tower components shall conform to the following standards (Chinese Standards) and customer's requirements.
Steel pipe/angle/hybrid tower welding requirements
1 )we used CO2 welding and submerged arc auto welding or other methods.
2 )Welded seam shall be full penetration and grinded.
3 )The welded product has no fissure, scar, overlap, layer or other defects.
