Solar Street Outdoor Light Pole 8m Height ASTM A123 Grey Color Painting
Solar Street Outdoor Light Pole 8m Height ASTM A123 Grey Color Painting
Solar Street Outdoor Light Pole 8m Height ASTM A123 Grey Color Painting
Solar Street Outdoor Light Pole 8m Height ASTM A123 Grey Color Painting
Specifications
Brand Name :
GUANGXIN
Model Number :
GX-1309
Certification :
ISO9001
Place of Origin :
Guangzhou, China
MOQ :
100pcs
Price :
USD40-80 per piece
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
2000 sets per month
Delivery Time :
20-30 days
Packaging Details :
air bubble sheet package
Name :
Solar Street Outdoor Light Pole Design 8m Height
Surface Finish :
Hot dip galvanization plus powder coating(optional)
Galvanization Standard :
ASTM A123/ ISO 1461
Color :
Grey Color Painting
Welding Standard :
AWS D1.1
Welding Method :
CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
Pole Shape :
conical, tapered, octangular, polygonal, round etc.
Arms :
1 arms or customized ODM
Applications :
Traffic monitor, public security CCTV, parking lotsurveillance etc.
Transportation :
by Sea to clients destination port
Description

Solar Street Outdoor Light Pole Design 8m Height

Specification:

Descriptions Steel poles for mounting lights, CCTV camera, guideboards, billboards etc. Double Arm Street Light Pole
Material Low carbon weldable structural steel
Grade GB Q235, Q345, BS4360, ASTM A36 etc.
Yield Strength 235-355MPa
Height 5m to 12m or other specified height
Thickness 4mm to 15mm, depending on height of pole.
Pole Shape Conical/tapered, straight round/cylindrical, square or rectangular, polygonal etc.
Diameter or Dimensions Subject to height of pole and required mechanical properties.
Design Single, dual or multiple straight or curved arms and brackets
Surface Finish Hot dip galvanization plus powder or PVDF coating (optional)
Galvanization 65-100 Microns
Coating 35-80 Microns
Color Silver, grey, black, white, blue, yellow etc.
Applications Roadways, streets, highways, stadiums, public sqaures, airports, railway stations, communities, parking lots, gardens etc.

Galvanized Steel Lighting Pole with Single Arm

Solar Street Outdoor Light Pole 8m Height ASTM A123 Grey Color Painting

Features:

1.The steel light poles are designed with single, dual or multiple arms.

2. Brackets for mounting lamps, solar panels, CCTV cameras or other facilities as per requests.

3. The designs of arms and brackets are also customized to requirements for different connectors of luminairs or other facilities.

4. With custom special designs, the light poles are not only used for lighting, monitoring or traffic signal control but also for city landscape decorations.

5. The popular steel light poles include tubular steel pole, solar street light pole, conical or tapered light pole, hexagonal or polygonal lighting pole, straight round street light pole and octagonal lighting pole.

6. There are 2 ways of installation of the steel poles, one is directly buried and the other way is fixed by base plate with bolts and nuts.

7. Application: Roadways, streets, highways, stadiums, public sqaures, airports, railway stations, communities, parking lots, gardens etc.
