55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising
55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising
55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising
55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising
55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising
55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising
55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising
55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising
Specifications
Brand Name :
YD
Model Number :
55 LCD VIDEO WALL
Certification :
ISO9001 , CE , RoHS , FCC
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
3 , 000pcs per month
Delivery Time :
7 working days upon payment
Packaging Details :
wooden case
Surface :
Anti-glare
Backlight :
LED
Input Voltage :
AC 220v-250v
Cooling :
Low Noise Fans
Panel Size :
55 Inch
Bezel :
1.7/3.5mm
Refresh Rate :
60Hz
Resolution :
1920x1080
Operating Temperature :
0~50°C
Installation :
Wall Mount; Floor Stand' Cabinet Type
Description

55 Inch LCD Video Wall HDMI Rich Color High Brightness Commercial Advertising Screens Monitors 1.7mm Bezel

LCD digital wall technology is a high quality image representative of serial transmission, mainly used in some professional field of television and radio and television, the product supports audio embedded solution, at the same time, supports the highest resolution to 1080p 60Hz, which should be more extensive.

55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising

LCD Video Wall Feature

1. LCD Industrial HD&High-brightness narrow edge LCD.

2. Narrow Edge Design: Minimum 1.8mm.

3. High Resolution Ratio: 1920*1080

4. High-brightness: 700cd/sqm

5. Super wide visual angle:178(H)/178(V).

LCD Video Wall​ Specifications

LCD Technology Samsung LG BOE
Active Screen Diagonal 55"
Pixel Pitch(WxH) 0.630x0.630mm
Active Display Area(WxH) 1209.6x680.4mm
Panel Dimension(WxHxD) 1211.4x682.2x53.3mm
Total Bezel Width 1.7 mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backlight System LED
Luminance(nits) 700cd/sqm
Contrast 5000:1 (typ.)
Viewing Angle H 178°|V 178°
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000h

Performance Features as follows:

Support a variety of signal ports.

Built-in splicing module, Support splice function

Support Creating one window(PIP) across the screen,roaming service,scaling,PIP

Support matrix joint control.

Dynamic image without motion trail

Splicing image processing RS-232(RJ-45)loop-circuit input/output.

Input by remote control with wire,mobile receiver head.

55 Seamless Splicing LCD Video Wall 1.7mm Bezel For Commercial Advertising

Business Organizations supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations

Banks, negotiable securities, funds, insurance companies, pawnshops;

Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places

subway, airports, stations, gas stations, toll stations, bookstores, parks,

exhibition halls, stadiums, museums, convention centers, ticket agencies,

HR market, lottery centers; Real Estate Property: Apartments, villas, offices,

commercial buildings, model rooms, property brokers;
Entertainments

Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes,

Internet bars, beauty shops, golf course

Contact Steve Online: +86 18520820622
