0.15t/H Solid Fuel 150kg Vertical Biomass Steam Generator
0.15t/H Solid Fuel 150kg Vertical Biomass Steam Generator
0.15t/H Solid Fuel 150kg Vertical Biomass Steam Generator
0.15t/H Solid Fuel 150kg Vertical Biomass Steam Generator
0.15t/H Solid Fuel 150kg Vertical Biomass Steam Generator
0.15t/H Solid Fuel 150kg Vertical Biomass Steam Generator
0.15t/H Solid Fuel 150kg Vertical Biomass Steam Generator
0.15t/H Solid Fuel 150kg Vertical Biomass Steam Generator
Specifications
Brand Name :
Swet
Model Number :
LSS0.15-0.7-S
Certification :
ISO9001
Place of Origin :
Henan Province, China
MOQ :
1
Price :
3000USD-3600USD
Supply Ability :
1500 sets per year
Delivery Time :
15-30 days after payment received
Packaging Details :
The boiler is covered with a waterproof film and the transport package is a wooden box.
Rated evaporation :
150kg/h
Rated pressure :
0.7Mpa
Rated steam temperature :
170℃
Thermal efficiency :
87%
Water capacity :
<29L
Length :
1600mm
Width :
900mm
Height :
1900mm
Full load biomass consumption :
24kg/h
Style :
vertical
Design fuel :
biomass pellets
Evaporation :
110kw
Boiler evaporation :
90000Kcal
Output :
steam
The calorific value of biomass pellets :
4200Kcal/kg
Shipping weight :
0.7 ton
Steam outlet :
DN15
Water intake :
DN15
Drain valve :
DN20
Description

0.15t/h solid fuel electric generator 150kg vertical biomass boiler

Environmental protection and durability: gas steam boiler with a new multi-tube cyclone dust collector and energy-saving integrated structure, greatly reducing the flue gas temperature, improve thermal efficiency, environmental protection requirements to meet the new national standards; meticulous design, the use of table steel is much higher than peers Standard, the main body of gas steam boiler in strict accordance with the A-class boiler manufacturing process requirements, by holding the national boiler pipe pressure vessel welder welder for boiler welding, durable.
Sophisticated and beauty: gas steam boiler innovation and improvement to enhance the practicality, modeling novel, especially small size, easy to install without basic, product appearance, soft colors, and the environment coherent, full of artistic sense.
The gas steam boiler furnace adopts the three-dimensional air circulation of three sides and a second oxygenating mouth; complete combustion and no visible smoke emissions; fully meeting the national emission requirements on the boiler.
The gas steam boiler control system security protection includes multiple functions such as low water level, overheating, and overpressure etc. to ensure no security risks.
Small steam boiler technical parameters
Item LSS0.1-0.7-S LSS0.15-0.7-S LSS0.2-0.7-S
Rated evaporation Kg/h 100 150 200
Rated pressure Mpa 0.7 0.7 0.7
Rated steam temperature ℃ 170 170 170
Design thermal efficiency % 87 87 87
Water capacity L <29 <29 <29
Steam outlet DN 15 15 20
Water intake DN 15 15 15
Drain valve DN 20 20 25
Dimensions L mm 1500 1600 2000
W mm 900 900 1000
H mm 1800 1900 2000
Shipping weight T 0.65 0.7 1
Full load biomass consumption Kg/h 16 24 32

Small steam boiler applicable scenario
Textile industry: shrinking machine, dry cleaning machine, dryer, washing machine, dehydration machine, printing, ironing machine, iron and other equipment.
Food machinery industry: steamer, tofu machine, sterilization tank, packaging machines, paint equipment, sealing machines and other equipment.
Other industries: automotive steam cleaning industry, hotels, hotels, schools, enterprises and other hot water supply, bridges, railway concrete conservation and other industries.
Our engineering case
Company Information
Henan kaifeng Swet (original name Desheng) Boiler Co.Ltd was established in 1954 ,We have continued to provide customers with more than 60 years of quality service, known as the king of China's boiler.
It’s the national designated A-class boilers and D1, D2 class pressure vessel manufacturing key enterprises and has passed ISO9001 international quality management certification system certification.
It holds level 1 boiler installation permit ,National special equipment manufacturing license ,National special equipment installation remould maintenance permits and so on.
In 1979 the world's first circulating fluidized bed boiler developed by the Austrian company in Finland.
In 1987 China's first circulating fluidized bed boiler was born in our factory.
In 2016 In order to meet current emissions and reduce energy consumption requirements, our company launched efficient low-emission energy-saving circulating fluidized bed boiler, has been identified by the national institute of special equipment.
OUR ENTERPRISE HONOR
OUR ADVANTAGES
Chinese Academy of Sciences circulating fluidized bed boiler research and development base.
China 's top ten boiler manufacturing enterprises.
Shanghai Industrial Boiler Research Institute Industrial Boiler Technology Development Relying on the unit.
North China Water Conservancy and Hydropower University teaching and research base.
The China’s first circular flow bed (CFB)boiler manufacturer.
