Specifications
Brand Name :
SWET
Model Number :
SZL30-2.5-T-0029
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram,Cash or on the basis of mutual agreement
Supply Ability :
1500 Set/Sets Per Year
Delivery Time :
25-35 work days
Packaging Details :
The main part of the boiler is bare packaging and wood packaging, container or according to packaging needs.
Rated evaporation :
30t/h
Working pressure :
2.5MPa
Return water temperature :
104℃
Keywords :
Chain grate boiler
Steam temperature :
224℃
Boiler dimensions :
13000x7100x9500mm
Model :
SZL25-2.5-T-0029
Thermal efficiency :
85%
Description

Industrial Full Automatic Chain Grate Boiler Low Pressure Energy Saving Boiler

Product Description

1. Adopting original furnace results and unique combustion technology. Fully integrate and integrate the new technology, new achievements, new materials and new technology of the boiler, improve and enhance the combustion, heat transfer, energy saving and environmental protection performance of the boiler.

2. Biomass fuels have the characteristics of high volatility and low ignition point. So theoretically it is not fundamentally different from the structure of traditional coal-fired boilers. Every boiler that burns coal can burn biomass fuel.

3. Relative to the traditional boiler space is large, while the rational layout of the secondary air, is conducive to the combustion of biomass fuel instantaneous precipitation of a large number of volatile fully burned. To ensure that flue gas residence time in the furnace to prevent small carbon particles are taken out of the furnace to ensure that the fuel fully burned in the furnace.

Product Features


1. Automatic operation easy to operate;

2. High thermal efficiency gas production;

3. Multiple protection safe to;

4. Small size and beautiful appearance.

Technical Parameters

Boiler type and parameter list of double boiler barrel series chain grate boiler

Boiler model

Rated evaporation

Working pressure

Steam temperature

Water supply temperature

Exhaust temperature

Thermal efficiency

Boiler dimensions

Unit

t/h

Mpa

℃

℃

℃

%

mm

SZL10-1.25-T

10

0.7/1.0/1.25

170/184/194

104

150

≥80

8830x3180x5730

SZL15-1.6-T

15

1.0/1.25/1.6

184/194/204

104

155

≥80

14000x4174x614

SZL20-1.6-T

20

1.0/1.25/1.6

184/194/204

104

155

≥80

15820x4620x8680

SZL25-2.5-T

25

1.25/1.6/2.5

194/204/224

104

160

≥80

12800x6000x8420

SZL30-2.5-T

30

1.25/1.6/2.5

194/204/224

104

160

≥80

13000x7100x9500

SZL35-2.5-T

35

1.25/1.6/2.5

194/204/224

104

160

≥80

3000x7600x9800
