Specifications
Brand Name :
SWET
Model Number :
DHX35-1.25-0020
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
700 Set/Sets Per Year
Delivery Time :
shipped in 60 after payment
Packaging Details :
1. Industrial Steam Boiler in nude package. 2. All boiler accessories in plywood or wooden case. 3.Delivery Detail :Shipped in 60 days after payment
Rated evaporation :
35t/h
Work pressure :
1.25MPa
Steam temperature :
194℃
Feed water temperature :
104℃
Dimensions :
13800x10320x26815mm
Thermal efficiency :
91%
Description

35 tons Biomass Combustion Circulating Fluidized Bed Steam Boiler For Power Plant

Product description

1. HD circulating fluidized bed boiler is energy saving which is mainly installed at power plants to generate electricity.

2. HD CFB boiler adopts stationary equipment design theory and CFB boiler technical parameter

Structure Feature

1. Natural circulation water-tube boiler single boiler barrel, an n-shaped structure.

2. The hearth is membrane water wall hanging closed structure.

3. Adopting the water cooling air chamber and a water cooling cloth wind plate, under the bed of water.

4. Separated by high temperature insulation volute cyclone cylider, outer furnace arrangement.

5. Superheater, economizer, air preheater is arranged in the tail shaft.

Circular flow bed CFB boiler technical parameters

Model Rated evaporation Work pressure Steam temperature Water supply temperature Fuel consumption Thermal efficiency Dimensions
Unit t/h MPa ℃ ℃ Kg/h % mm(Long x wide x high)
DHX20-1.25 20 1.25 194 104 2475 91 12000x8160x22120
DHX20-1.6 20 1.6 204 104 2483 91 12000x8160x22120
DHX20-2.5/400 20 2.5 400 104 2934 91 12000x8160x22120
DHX25-1.25 25 1.25 154 104 3003 91 13000x8610x23170
DHX25-1.6 25 1.6 204 104 3100 91 13000x8610x23170
DHX25-2.5/400 25 2.5 400 104 3692 93 13000x8610x23170
DHX30-1.25 30 1.25 194 104 3712 93 12170x9200x25500
DHX30-1.6 30 1.6 204 104 3724 93 12170x9200x25500
DHX30-2.5/400 30 2.5 400 104 4431 93 12170x9200x25500
DHX35-1.25 35 1.25 194 104 4331 91

13800x10320x26815
