Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature
Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature
Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature
Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature
Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature
Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature
Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature
Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature
Specifications
Brand Name :
SWET
Model Number :
DHX30-2.5/400-0019
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
USD 250000 - 300000 Set/Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
700 Set/Sets Per Year
Delivery Time :
shipped in 60 after payment
Packaging Details :
1. Industrial Steam Boiler in nude package. 2. All boiler accessories in plywood or wooden case. 3.Delivery Detail :Shipped in 60 days after payment
Rated evaporation :
30t/h
Work pressure :
2.5MPa
Steam temperature :
400℃
Feed water temperature :
104℃
Dimensions :
12170x9200x25500mm
Thermal efficiency :
91%
Description

30 Tons Quick Loading Vertical Full Automatic Circulating Fluidized Bed Boiler For Power Plants

Product description

1. Circulating fluidized bed is of low-temperature combustion, therefore, nitrogen oxides emissions of such boiler is much lower than that of coal-powder boiler, and such boiler could directly desulfurized during combustion process.

2. Circulating fluidized bed boiler with high desulfurization rate is economical.

3. Circulating fluidized bed boiler could adopt various coal types and has high combustion efficiency, which is especially suitable for low quality, low calorific value coal.

Benefits

1. Greatest Fuel Flexibility

2. Best overall solution for high moisture fuels.

3. Ability to burn fuels containing mid-level amounts of alkali.

4. Proficient at combusting fuels from the extreme low-end to extreme high-end moisture contents.

Circular flow bed CFB boiler technical parameters

Model Rated evaporation Work pressure Steam temperature Water supply temperature Fuel consumption Thermal efficiency Dimensions
Unit t/h MPa ℃ ℃ Kg/h % mm(Long x wide x high)
DHX20-1.25 20 1.25 194 104 2475 91 12000x8160x22120
DHX20-1.6 20 1.6 204 104 2483 91 12000x8160x22120
DHX20-2.5/400 20 2.5 400 104 2934 91 12000x8160x22120
DHX25-1.25 25 1.25 154 104 3003 91 13000x8610x23170
DHX25-1.6 25 1.6 204 104 3100 91 13000x8610x23170
DHX25-2.5/400 25 2.5 400 104 3692 93 13000x8610x23170
DHX30-1.25 30 1.25 194 104 3712 93 12170x9200x25500
DHX30-1.6 30 1.6 204 104 3724 93 12170x9200x25500
DHX30-2.5/400 30 2.5 400 104 4431 93 12170x9200x25500
DHX35-1.25 35 1.25 194 104 4331 91

13800x10320x26815
