30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation
30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation
30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation
30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation
30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation
30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation
30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation
30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation
Specifications
Brand Name :
SWET
Model Number :
DHX30-1.6-0017
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
700 Set/Sets Per Year
Delivery Time :
shipped in 60 after payment
Packaging Details :
1. Industrial Steam Boiler in nude package. 2. All boiler accessories in plywood or wooden case. 3.Delivery Detail :Shipped in 60 days after payment
Rated evaporation :
30t/h
Work pressure :
1.6MPa
Steam temperature :
204℃
Feed water temperature :
104℃
Fuel consumption :
3103kg/h
Thermal efficiency :
91%
Description

30t/h Rice Husk Fired Circulating Fluidized Bed Boiler For Power Pant

Product description

1. The fuel adaptability is strong, can meet a variety of fuel combustion.

2. High degree of automation, can keep the boiler safe and economic operation in long time.

3. The boiler combustion efficiency is as high as 95% ~ 99%, fuel efficiency is high, the boiler thermal efficiency can reach above 87%, energy saving, high efficiency.

4. Using the exhaust temperature cyclone separating device, bed material high collection rate, furnace heat transfer coefficient is high, the overload ability.

5. The boiler load adjustment range is big, can be adjusted within the scope of 110% ~ 30%, particularly suitable for large range of boiler load fluctuations.

6. The bed material can be added in the limestone, combustion reaction with SO2 in flue gas generated in the process of sulfate, the desulfurization effect meet the requirements of environmental protection, at the same time chamber of a stove or furnace combustion temperature is low, can inhibit the formation of NOX, truly green burning.

Circular flow bed CFB boiler technical parameters

Model Rated evaporation Work pressure Steam temperature Water supply temperature Fuel consumption Thermal efficiency Dimensions
Unit t/h MPa ℃ ℃ Kg/h % mm(Long x wide x high)
DHX20-1.25 20 1.25 194 104 2475 91 12000x8160x22120
DHX20-1.6 20 1.6 204 104 2483 91 12000x8160x22120
DHX20-2.5/400 20 2.5 400 104 2934 91 12000x8160x22120
DHX25-1.25 25 1.25 154 104 3003 91 13000x8610x23170
DHX25-1.6 25 1.6 204 104 3100 91 13000x8610x23170
DHX25-2.5/400 25 2.5 400 104 3692 93 13000x8610x23170
DHX30-1.25 30 1.25 194 104 3712 93 12170x9200x25500
DHX30-1.6 30 1.6 204 104 3724 93 12170x9200x25500
DHX30-2.5/400 30 2.5 400 104 4431 93 12170x9200x25500
DHX35-1.25 35 1.25 194 104 4331 91

13800x10320x26815

30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation

30t/H Rice Husk Fired Circulating Fluidized Bed Boiler High Degree Automation
