Professional 25T Circulating Fluidized Bed Boiler Good Heat Resistance
Professional 25T Circulating Fluidized Bed Boiler Good Heat Resistance
Professional 25T Circulating Fluidized Bed Boiler Good Heat Resistance
Professional 25T Circulating Fluidized Bed Boiler Good Heat Resistance
Professional 25T Circulating Fluidized Bed Boiler Good Heat Resistance
Professional 25T Circulating Fluidized Bed Boiler Good Heat Resistance
Professional 25T Circulating Fluidized Bed Boiler Good Heat Resistance
Professional 25T Circulating Fluidized Bed Boiler Good Heat Resistance
Specifications
Brand Name :
SWET
Model Number :
DHX25-1.6-0011
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
700 Set/Sets Per Year
Delivery Time :
shipped in 60 after payment
Packaging Details :
1. Industrial Steam Boiler in nude package. 2. All boiler accessories in plywood or wooden case. 3.Delivery Detail :Shipped in 60 days after payment
Rated evaporation :
25t/h
Work pressure :
1.6MPa
Steam temperature :
204℃
Feed water temperature :
104℃
Dimensions :
13000x8610x23170mm
Thermal efficiency :
91%
Description

25T Automatic Control Coal Fired Steam Circulating Fluidized Bed Boiler

Technical features

1. This CFB boiler which has the good performance and high reliability is deigned and manufactured according to the civil and abroad CFB boiler’s design, manufacture and operation’s successful experience mixed with the our SWET specific characteristics.

2. The water system is natural circulation system and the boiler adopts the whole airproof high temp. Cyclone separator whose features are high separating efficiency and reliable operation

Supply scope

1. Industrial gas commonly used in chemical industry, building materials, ceramics, steel, non-ferrous metal smelting, food, textile and other industries.

2. Circulating fluidized bed gasifier specific applications include rotary kiln drying, ceramic building materials, casting industry heat treatment, alumina roasting, high-temperature sterilization of food, textile printing and dyeing products.

Circular flow bed CFB boiler technical parameters

Model Rated evaporation Work pressure Steam temperature Water supply temperature Fuel consumption Thermal efficiency Dimensions
Unit t/h MPa ℃ ℃ Kg/h % mm(Long x wide x high)
DHX20-1.25 20 1.25 194 104 2475 91 12000x8160x22120
DHX20-1.6 20 1.6 204 104 2483 91 12000x8160x22120
DHX20-2.5/400 20 2.5 400 104 2934 91 12000x8160x22120
DHX25-1.25 25 1.25 154 104 3003 91 13000x8610x23170
DHX25-1.6 25 1.6 204 104 3100 91 13000x8610x23170
DHX25-2.5/400 25 2.5 400 104 3692 93 13000x8610x23170
DHX30-1.25 30 1.25 194 104 3712 93 12170x9200x25500
DHX30-1.6 30 1.6 204 104 3724 93 12170x9200x25500
DHX30-2.5/400 30 2.5 400 104 4431 93 12170x9200x25500
DHX35-1.25 35 1.25 194 104 4331 91

13800x10320x26815
