Specifications
Brand Name :
SWET
Model Number :
Q19/1100-6-1.25-0009
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Cash or on the basis of mutual agreement
Supply Ability :
200 Set/Sets Per Year
Delivery Time :
Shipped in 15 days after payment
Packaging Details :
Standard Packaging
Flue gas volume :
19000m³/h
Flue gas temperature :
1100℃
Evaporation :
6T/H
Steam pressure :
1.25MPa
Steam temperature :
Saturated Vapor
Fuel :
Waste heat
Description

1.25MPa Industrial Automatic Control Waste Heat Boiler Central Heating

Product Description

1. Waste heat boiler is an auxiliary equipment that comprehensively utilizes waste heat of industrial furnace and is generally installed in the flue to absorb the waste heat (or waste heat) of the discharged flue gas to generate steam and reduce the flue gas temperature.

2. If not installed fan, placed waste heat boiler, the total resistance less than chimney pumping force. If the induced draft fan, because the draft fan can only withstand temperatures below 250 ℃, the flue gas temperature should be reduced to 250 ℃ below, we must set the waste heat boiler, in order to ensure the safe operation of the entire furnace system.

Product Features

1. The heat load is unstable and will change with the production cycle.

2. Flue gas dust content.

3. The flue gas is corrosive.

4. waste heat boiler installation site conditions will be subject to restrictions, in addition there is also how the process with the previous paragraph and so on.

Technical Parameters

Model

Flue gas volume

Flue gas temperature

Evaporation

Steam pressure

Steam temperature

Unit

m³/h

℃

t/h

MPa

℃

Q19/1100-6-1.25

19000

1100

6

1.25

Saturated Vapor

Q29/800-10-2.5

29000

800

10

2.5

Saturated Vapor

QZ9/1150-4-0.4

9000

1150

4

0.4

Saturated Vapor

Q15-420-8-2.4/350

15000

420

8

2.4

350

Q16-740-5-3.82/440

16000

740

5

3.82

440

Q120/900-82-3.82/450

120000

900

82

3.82

450

QC28/720-9-1.0

12000

720

9

1.0

Saturated Vapor

QC18/1200-4-1.25/220

18000

1200

4

1.25

220
