Specifications
Brand Name :
SWET
Model Number :
WNS6-1.25-Y、Q-3010
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
1500 Set/Sets Per Year
Delivery Time :
25-30 work days
Packaging Details :
The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements
Rated evaporation :
6 t / h
Rated working pressure :
1.25/1.6 MPa
Rated steam temperature :
194/204℃
Outline dimension :
5470*2770*3195mm(L*W*H)
Gas consumption :
433.51 Nm³/h
Color :
Based on customer's needs
Keywords :
gas steam boiler
Model :
WNS6-1.25-Y、Q-3010
Description

6T/h Mini Induction Heating Oil Gas Fuel Steam Boiler With Low Pressure


Product description

The gas steam boiler is equipped with A48Y-16C full-opening safety valve (DN80) two. Frequency conversion pump technology to achieve automatic continuous water supply


Product advantages

1. 100% corrugated furnace and spirally corrugated tube, can absorb flame heat effectively, thermal efficiency can be more than 96%.

2. The gas steam boiler body with full butt weld wet back structure, low profile full-wave furnace, boiler structure flexibility and thermal expansion of a good, safe and reliable.

3.PLC modular control system enhanced energy management system, offers significant advancements including many new individual monitoring points.

Specification

WNS series of automatic gas (oil) steam energy-saving boiler product selection table
Model Rated evaporation Work pressure Steam temperature Feed water temperature Air consumption Test efficiency Transport dimensions
Unit t/h MPa ℃ ℃ Nm³/h % mm
WNS20-2.5-Q(Y) 20 2.5 226 105 1407.5 97.62 8660x3520x4831
WNS20-1.25(1.6)-Q(Y) 20 1.25/1.6 194/204 105 1459 97.51 8870x3550x3750
WNS15-1.0(1.25)(1.6)-Q(Y) 15 1.0/1.25/1.6 184/194/204 105 1126 97.2 7450x3520x4090
WNS10-1.25(1.6)-Q(Y) 10 1.25/1.6 194/204 105 837.25 96.75 6370x2812x3514
WNS8-1.25(1.6)-Q(Y) 8 1.25/1.6 194/204 105 659.25 96.7 6000x2920x3430
WNS6-1.25(1.6)-Q(Y) 6 1.25/1.6 194/204 105 433.51 96.58 5470x2770x3195
WNS5-1.25(1.6)-Q(Y) 5 1.25/1.6 194/204 20 409.33 96.48 5160x2410x3015
