Specifications
Brand Name :
SWET
Model Number :
QXS(SZS)21-1.25（1.6）-Y,Q-3009
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
1500 Set/Sets Per Year
Delivery Time :
25-30 work days
Packaging Details :
The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements
Leaving Water Temperature :
115(130)(150) ℃
return water temperature :
70(90)℃
efficiency :
97.13 %
Model :
QXS(SZS)21-1.25（1.6）-Y,Q-3009
Keywords :
hot water boiler
Rated thermal power :
21 MW
nominal working pressure :
1.0(1.25)(1.6) MPa
Color :
Customer requirements
Description

Simple Structure Gas Fired Hot Water Boiler With Safety Operation


Product description

1. The company's SZS series of fuel (gas) boiler is a typical D-type arrangement of double-drum longitudinal-type water tube boiler, according to the size of the boiler divided into fast-type and assembly type.

2. SZS-type gas-fired gas boiler is a dual-drum vertical type "D" type arrangement quick assembly water tube boiler

Product advantages

1. High thermal resistance of the boiler material as a thermal insulation layer, good thermal insulation properties.

2. Hot water boiler under the support method, the heat can be freely expanded.

3. The hot water boiler assembly and quick installation structure, effectively shorten the installation cycle.

4. The finned tube steel economizer, the effective control of the exhaust gas temperature, high thermal efficiency of the boiler.


5. Hot water boiler feed water with continuous automatic adjustment, and with high and low water level alarm protection chain.

FAQ

1.Q: Can I get guarantee of products?

A: Yes, every product is 1 year quality warranty under customer correct using the products.

2.Q: Do you have any Certificate?

A: Yes. Each of our boiler has China GB and ISO9001certificate

3. Q: How can I pay you?

A: T/T is very well used.We also accept other ways, depending on the circumstances

4. Q: What about the production?

A: Produce time is 30 days

Product parameters

SZS water pipe type full automatic gas-fired hot water energy-saving boiler

Model

Rated thermal power

nominal working pressure

Leaving Water Temperature

return water temperature

efficiency

gas consumption

Overall dimensions of transportation

Unit

MW

MPa

℃

℃

%

Nm³/h

mm

QXS(SZS)58

58

1.25(1.6)(2.5)

130(150)

70(90)

98.3

6196

15360*7570*8318

QXS(SZS)48

48

1.25(1.6)(2.5)

130(150)

70(90)

98.09

5048

15600*9500*7920

QXS(SZS)29

29

1.25(1.6)

130(150)

70(90)

97.8

3150

9685*6870*7180

QXS(SZS)21

21

1.0(1.25)(1.6)

115(130)(150)

70(90)

97.13

2328

10130*6170*6134

QXS(SZS)14

14

1.0(1.25)(1.6)

115(130)(150)

70(90)

97.02

1558

8120*3385*3750

QXS(SZS)10.5

10.5

1.0(1.25)(1.6)

115(130)(150)

70(90)

97

1136

7250*3682*3820

QXS(SZS)7

7

0.7(1.0)(1.25)

95(115)(130)

70(90)

96.87

754

6770*3210*3775

QXS(SZS)7

7

1.25

115

70(90)

95.76

763

6760*2780*3299

QXS(SZS)5.6

5.6

0.7(1.0)(1.25)

95(115)(130)

70(90)

95.57

619.2

6450*2956*3620

QXS(SZS)4.2

4.2

0.7(1.0)(1.25)

95(115)(130)

70(90)

95.36

456.7

5700*3105*3410

QXS(SZS)2.5

2.5

0.7(1.0)(1.25)

95(115)

70(90)

95.13

314

5160*2840*2930

Performance features: symmetrical furnace, uniform distribution, good cooling, sufficient combustion, long service life, stable output
