Specifications
Brand Name :
SWET
Model Number :
QXS(SZS)5.6-1.6-Y,Q-3018
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
1500 Set/Sets Per Year
Delivery Time :
25-30 work days
Packaging Details :
The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements
Leaving Water Temperature :
95(115)(130) ℃
efficiency :
95.57 %
Model :
QXS(SZS)5.6-1.6-Y,Q-3018
Keywords :
hot water boiler
Rated thermal power :
5.6 MW
nominal working pressure :
0.7(1.0)(1.25)MPa
return water temperature :
70(90) ℃
color :
Customer requirements
Description

Safe And Efficient Large-Scale Hot Water Boiler For Chemical Industry


Product description

1. SZS series of fuel (gas) boiler for the classic D-type layout of the boiler.

2. The use of the international fashion D-type layout, wet back structure, large-volume combustion chamber design, the combustion more fully.

3. The furnace adopts the membrane type water wall structure, the whole boiler adopts the hermetic inner guard of the totally enclosed welding structure, and the furnace wall has good sealing performance

Product advantages

1. High efficiency, low consumption, low pollution, green products

2. Convenient operation and convenient installation

3. Simple and reasonable structure

4. The entire boiler seat in the rigid base, easy installation and transportation.

FAQ

1. Q: Can I get guarantee of products?
A: Yes, every product is 1 year quality warranty under customer correct using the products.

2. Q: Do you have any Certificate?
A: Yes. Each of our boiler has China GB and ISO9001certificate

3. Q: How can I pay you?
A: T/T is very well used.We also accept other ways, depending on the circumstances

4. Q:What's your Warranty?

A:12 months, during which all parts damaged because of quality problem will be changed for free.



Product parameters

SZS water pipe type full automatic gas-fired hot water energy-saving boiler

Model

Rated thermal power

nominal working pressure

Leaving Water Temperature

return water temperature

efficiency

gas consumption

Overall dimensions of transportation

Unit

MW

MPa

℃

℃

%

Nm³/h

mm

QXS(SZS)48

48

1.25(1.6)(2.5)

130(150)

70(90)

98.09

5048

15600*9500*7920

QXS(SZS)29

29

1.25(1.6)

130(150)

70(90)

97.8

3150

9685*6870*7180

QXS(SZS)21

21

1.0(1.25)(1.6)

115(130)(150)

70(90)

97.13

2328

10130*6170*6134

QXS(SZS)14

14

1.0(1.25)(1.6)

115(130)(150)

70(90)

97.02

1558

8120*3385*3750

QXS(SZS)10.5

10.5

1.0(1.25)(1.6)

115(130)(150)

70(90)

97

1136

7250*3682*3820

QXS(SZS)7

7

0.7(1.0)(1.25)

95(115)(130)

70(90)

96.87

754

6770*3210*3775

QXS(SZS)7

7

1.25

115

70(90)

95.76

763

6760*2780*3299

QXS(SZS)5.6

5.6

0.7(1.0)(1.25)

95(115)(130)

70(90)

95.57

619.2

6450*2956*3620

QXS(SZS)4.2

4.2

0.7(1.0)(1.25)

95(115)(130)

70(90)

95.36

456.7

5700*3105*3410

Performance features: symmetrical furnace, uniform distribution, good cooling, sufficient combustion, long service life, stable output
