Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100units per week
Delivery Time :
Within 35 days
Packaging Details :
nude
Working weight :
220t/220000kgs
Engine power :
360KW
Crane condition :
new produced
Dimension :
15545×3000×3990
Description

XCT200 truck crane, XCMG brand, with lifting weight/operating weight 200t, 360KW engine power, export to Africa, South America...

Advantages:

New appearance, K-shaped legs, compact structure, leading performance, safe and reliable, economic and environmental protection, tailored for users a boutique model.

• Lifting performance of the overall lead, the machine lifting performance above the industry's highest level of 15%;

• Low speed, large torque power system, perfect combination of optimum power and optimal economy

• Working condition automatic planning technology, hoisting operation safe and efficient;

• Newly upgraded exterior styling with humanized design, more comfortable driving control

Specification:

Model XCT220
Model

TAD722VE

OM460LA.E3A/1
Rated power(kW) 194/2100(360/1800)
Ratedtorque(N·m/r/min) 1050/1400(2200/1300)
Working weight(kg) 65000

Fron axle

Load weight(kg)

 8500×2+10000
Middle axle load weight (kg) 13000×2+9000
Rated lifting weight (kg) 220000
Outrigger distance(L×W) (m) 8.3×8.5(5.7)
Basic boom lift distance (kN·m) 6820
Basic boom lifting height (m) 13.6
Main boom max.lifting height (m) 67.7
Rotation plate rear turning radius (mm) 5215
Rotation speed (r/min) 1.8
Max.driving speed (km/h) 80
Max.gradability (%) 40
Approach angle (°) 19
Departure angle(°) 13
Min.Turning radius (m) 26
Min.ground clearance (mm) 300
Brake distance (m) ≤10
Fuel consumption (L) 85
Out dimension(mm) 15545×3000×3990
Wheelbase (m) 1420+2450+2150+1420+1505
Wheel track (m) 2610/2610/2610/2315/2315/2610
Engine model

TAD722VE

OM460LA.E3A/1
Engine rated power(kW/r/min) 194/2100(360/1800)
Engine max.output torque(N·m/r/min) 1050/1400(2200/1300)

The main products we deal with now are SINOTRUK HOWO, XCMG, SHANTUI, ZOOMLION and SANY.
Truck series:

1.dump trucks; cargo trucks
2. tractor trucks;
3. tanker trucks,( water tanker and oil tanker)
4. mixer trucks and concrete pump truck
5. mine dump trucks( 4x2 off-road mine tipper, 6x4 70T mine dump truck, 6x6 articualted dump trucks)
6. full drive trucks( 4x4. 6x6 and 8x8 Trucks)
7, garbage trucks( garbage compector truck, suction trucks)
8. truck cranes(normal road truck crane, truck mounted crane)
9. special trucks( wrecker trucks, military trucks...)
10. truck trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11. truck spare parts( howo, howo A7, golden prince all series trucks parts supplying)

Machine series:

1.Wheel loader,Backhoe loder, brick making machine

2.Roller,

3.Motor Grader,

4.Bulldozer,

5.Excavator,

6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane),

7,forklift and 45t contain reach stacker

8,paver and so on
