8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry
8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry
8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry
8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry
8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry
8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry
8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry
8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry
Specifications
Brand Name :
CIVL
Model Number :
CIVL
Certification :
ISO,CCC
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
200units/month
Delivery Time :
Within 35 days
Packaging Details :
nude
Color :
white
thickness :
3mm
pump :
Italy brand
Description

SINOTRUK HOWO Concrete Mixer Truck on HOT sale

Sinotruk concrete mixer tank truck 8M3 336hp 6x4 10tire with 1 spare tire and air conditioner

Specifications
(1) HOWO 6x4 Concrect Mixer Truck
(2) 6x4 Driving Model

(3) Horse Power: 226-420hp

8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry8M3 336hp 6x4 10 Tire Concrete Mixing Equipment With 1 Spare Tire And Air Conditioner / Cement Mixer Lorry

Technical Parameters

SINOTRUK HOWO 6x4 Mixer Truck for sample

Vehicle Main Dimensions (L x W x H)mm 9200x2550x3950
Weight in KGS Tare Weight 15500
Loading Capacity 25000
Front axles loading capacity 1x9000
Rear axles loading capacity 2x16000
Engine Brand SINOTRUK
Model WD615.47
Type 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Horse Power(HP) 371
Emission standard Euro Ⅱ
Gearbox HW19710 , 10 forwards & 2 reverse
Clutch Reinforced diaphragm clutch, diameter 430mm
Steering Gear ZF 8118,power steering, hydraulic steering with power assistance
Fuel tank (L) 300
Tire 12R22.5 Tubeless Radial Tire, 11 pieces including one spare tire
Brakes Service brake: dual circuit compressed air brake,Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels,Auxiliary brake: engine exhaust brake

Mixer Body

Thickness

 Mixer body 6mm high tensile strength steel
Blade 5 mm high tensile strength steel
Mixer body Volume M3 10

Hydraulics

 Motor, Pump Italian Brand ARK
Gear box Italian Brand TOP


www.road-machine.com
www.china-sinotruck.com

Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
