Dual Bands Gigabit Wireless Ap Router Home Use Stable Performance
Dual Bands Gigabit Wireless Ap Router Home Use Stable Performance
Dual Bands Gigabit Wireless Ap Router Home Use Stable Performance
Dual Bands Gigabit Wireless Ap Router Home Use Stable Performance
Specifications
Brand Name :
ZBT
Model Number :
WG108
Certification :
CE FCC ROHS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
5000pcs/month
Delivery Time :
5-8 work days
Packaging Details :
we will use our neutral packing box ; Size: 235*135*25.5mm, 1 pcs Openwrt Dual Core MT7621 Wifi Router For Home 192.168.1.1 Gigabit Port, 10pcs Openwrt Dual Core MT7621 Wifi Router For Home 192.168.1.1 Gigabit Port in 1 carton box.
Main chipset :
MT7621
application :
home use
flash :
16MB
Memory :
128MB
Name :
Dual Bands Wifi Router For Home Gigabit Port Router Access Point Routers
Frequency bands :
2.4ghz is normal power, 5.8ghz is high power
Description

Dual Bands Wifi Router For Home Gigabit Port Router Access Point Routers

Product Description

1.Simply Description:

ZBT-WG108 is used new MT7621 wireless solution, performs better and more functions. Stable wireless performance, stronger scalability , the Max transmission rate could be 1200Mbps(the 11ac PCIE mode is necessary) . 2.4G 300Mbps, 5G will be 880M(Max).Provide 1* USB2.0 interface, 1*TF Micro slot .

Software

Used stable and strong extensibility SDK system, Integration of a variety of network applications.

Support OEM&ODM

Hardware
Main Chipset MT7621A (880MHz)
2.4G Chip set MT7603EN
5.8G Chip set MT7612EN
RAM DDR2 256MB (MAX DDR2 256MB)
SPI FLASH 16MB (MAX 32MB)
Protocol

IEEE 802.11n.IEEE 802.11g.IEEE 802.11b.IEEE802.11ac.

IEEE802.11a
IEEE 802.3.IEEE 802.3u
RT Power

11n:17dBm±1dBm

11g: 17dBm±1dBm

11b: 19dBm±1dBm

11a: 19dBm±1dBm

11ac: 18dBm±1dBm
Reception Sensitivity

11N HT20 MCS7: -72dBm

11N HT40 MCS7: -69dBm

11G 54Mbps: -74dBm

11B 11Mbps: -86dBm

11A 54Mbps: -73dBm

11AC VHT20 MCS8: -66dBm
Work Channel

2.4GHz choose :1-13

5GHz choose :149.153.157.161.165
Wireless Rate Max 1200Mbps(depends on the 11AC mode)
Work Frequency 2.4GHz, 5.8GHz
Antenna 4* non-removable Omni Directional 5dBi antenna
Interface

1 *SIM card slot

1 *USB 2.0 port

1 *Micro SD card slot

1 *10/100/1000M WAN port(Auto MDI/MDIX)
4 *10/100/1000M LAN port(Auto MDI/MDIX)
LED PWR.2G.5G.WAN.LAN1.LAN2.LAN3.LAN4
Button Reset Button
Max Power consumption < 12W
Dimension(L*W*H) 164*137*35MM
Software
WAN Type PPPoE,Dynamic IP, Static IP
Work Mode

AP;

Router;
DHCP Server, Client, DHCP Client List, Address Reservation
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ
Firewall Security

Dos, SPI Firewall

IP Address Filter/MAC Address Filter/ Domain Filter

IP and MAC Address Binding
DDNS Support
VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)
Band Ctrl Support
Static Router Support
System Log Support
Other Function Mac clone
NTP Synchronize
Web firmware upgrade
Others
Work Environments

Operating Temperature:0℃ ~ 40℃；
Storage Temperature:-40℃~ 70℃；

Operating Humidity:10%~90% non-condensing
Storage Humidity:10%~90% non-condensing
Adapter 12V 1A
