Specifications
Brand Name :
ZBT,OEM
Model Number :
ZBT-WE4426
Certification :
CE,FCC,roHs
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram and PayPal
Supply Ability :
100000pcs/Month
Delivery Time :
5-8 working days for sample order
Packaging Details :
Hard carton
Product name :
Oem Openwrt Hotspot 300Mbps 4 Lan Port Enterprise Wifi Router With QCA9531 Chipset
Type :
Wireless
Wi-Fi Supported Frequency :
2.4G
Application :
Home
Chipset :
QCA9531
Interface :
1WAN/4LAN
Warranty :
1 year
Speed :
300Mbps
Description

Oem Openwrt Hotspot 300Mbps 4 Lan Port Enterprise Wifi Router With QCA9531 Chipset

Product Feature

The WE4426 uses the latest QC9531 Chipset wireless solution, performs better and more
function. Stable wireless performance, more functions , 2.4G 300Mbps.Provides 5*
10/100M self-adaption Ethernet ports. It is beautiful shape design to decorate home.So, it
is best choice to use in home.

Hardware
Main Chipset QC9531
RAM DDR2 128MB (MAX DDR2 256MB)
SPI FLASH 16MB (MAX 32MB)
Protocol IEEE 802.11n.IEEE 802.11g.IEEE 802.11b.IEEE 802.3u
RT Power

802.11b 18dBm±2dBm;

802.11g 15dBm±2dBm;

802.11n 15dBm±2dBm;

Reception Sensitivity

802.11b: -83dBm@10% PER

802.11g: -74dBm@10% PER

802.11n: -68dBm@10% PER

Work Channel 2.4GHz choose :1-13
Wireless Rate Max 300Mbps
Work Frequency 2.4GHz
Antenna 1*PCB antenna
Interface 1*10/100/100M WAN port(Auto MDI/MDIX)
4*10/100/100M LAN port(Auto MDI/MDIX)
LED Power,2.4G,WAN,LAN1,LAN2,LAN3,LAN4
Button Reset/WPS
Max Power consumption < 12W
Dimension(L*W*H) 245*120*120MM
Software
WAN Type PPPoE,Dynamic IP, Static IP
Work Mode

AP;

Router;

DHCP Server, Client, DHCP Client List, Address Reservation
Port Forwareding Virtual Server, Port Triggering, UPnP, DMZ
Firewall Security

Dos, SPI Firewall

IP Address Filter/MAC Address Filter/ Domain Filter

IP and MAC Address Binding

DDNS Support
VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)
Band Ctrl Support
Static Router Support
System Log Support
Other Function Mac clone
NTP Synchronize
Web firmware upgrade
Others
Work Environments

Operating Temperature:0℃ ~ 70℃;
Storage Temperature:-40℃~ 70℃;

Operating Humidity:10%~90% non-condensing
Storage Humidity:10%~90% non-condensing

Adapter 12V 1A
Authentication CE, FCC, RoHs
Other accessories

Power adapter

FAQ

1.Do you provide customer LOGO?
Yes, we accept to customize LOGO on firmware and hardware.


2.Do you accept PCBA orders only?
Of course, as a OEM/ODM manufacturer, we can provide PCBA in a short time with good quality.


3.Do you provide firmware support?
Sure thing, unlike other companies which are buying solutions from design company, we have our own firmware development team to support you in 100%.
