Metal Seated Floating Ball Valve , Forged Steel Ball Valve Inch 1/2 - 12
Metal Seated Floating Ball Valve , Forged Steel Ball Valve Inch 1/2 - 12
Specifications
Brand Name :
Zaval
Model Number :
BLFF910
Place of Origin :
China
MOQ :
2 pieces
Supply Ability :
negotiable
Delivery Time :
45 days
Packaging Details :
wooden case
Size Range :
1/2"-12" ( 25-300mm)
Pressure Ratings :
Class 150-2500 (PN16-PN420)
Design Standard :
ASME B16.34/BS5351/API6D
Ports :
Full & Reduced Bore
Body Style :
2 piece
Main Material :
Stainless Steel, Carbon Steel, Special Alloys
Operation :
Lever, Gear, Pneumatic Actuator
End Connection :
Flanged, BW
Applications :
Severe service
Description

Metal Seated Floating Ball Valve Forged & Casted 2PC, Inch1/2"-12" Class150-2500

Zaval metal-seated floating ball valves can be applied in wide pressure and temperature ranges (150LB~2500LB and -46~450℃). The metal seat provides an optimal resistance against wear caused by abrasive services or hard particles.

Design Feature

Metal Seated Floating Ball Valve , Forged Steel Ball Valve Inch 1/2

  1. Top flange design as per ISO 5211, optional actuators of gearbox, electric actuator and pneumatic actuator are available.
  2. Hard faced ball and the seat to satisfy the requirement of high hardness, high temperature resistance, wear resistance.
  3. With the help of the pre-loaded spring, the seat is able to maintain seal even in low operating pressure.
  4. Several designs of the seat to choose from, among which the dust proof seat design is available.

Specifications

Design ASME B16.34/API 6D
Face to Face ASME B16.10/API 6D
End to End ASME B16.10/API6D
End Flange ASME B16.5/B16.47A
BW End ASME B16.25
Test API 6D
Fire Safe Test API607/API 6FA
Special NCAE MR0175
