YMC0802SB-X01 Monochrome LCD Module 5.0V ST7066 Drive IC STN Blue
YMC0802SB-X01 Monochrome LCD Module 5.0V ST7066 Drive IC STN Blue
Specifications
Brand Name :
YZY
Model Number :
YMC0802SB-X01
Certification :
CE, ROHS
Place of Origin :
Guangdong, China
MOQ :
10 pieces
Price :
$1.38~2.32/pieces
Payment Terms :
T/T
Supply Ability :
10000 pieces
Delivery Time :
14-60 days
Description
YMC0802SB-X01 Monochrome LCD Module 5.0V ST7066 Drive IC STN Blue
This industrial grade YMC0802SB-X01 (0802B-2) monochrome LCD module adopts STN blue negative transmissive display structure with professional ST7066 driver IC. It features 5.0V drive voltage, high-brightness white backlight with 20MA current, 6 o'clock viewing angle, 1/16 duty and 1/5 bias design, as well as wide temperature adaptability. With stable performance, standard 14PIN interface and durable iron frame & PCB structure, it is widely applied in industrial control, measuring instruments, smart embedded systems, electronic devices and various equipment with high reliability and stable display demands, complying with industrial application standards.
Product Specifications
Display Type STN (Blue), Negative Transmissive Monochrome LCD
Module Model YMC0802SB-X01
Driver IC ST7066
Drive Mode 1/16 Duty, 1/5 Bias
Drive Voltage 5.0V DC
Viewing Angle/Direction 6 O'Clock
Backlight White Backlight, IF=20MA
Operating Temperature -20℃ ~ +70℃
Storage Temperature -30℃ ~ +80℃
Connection Type 14PIN Interface (GND/VDD/VO/RS/RW/E/DB0-DB7)
Structure Material PCB Board + Iron Frame
Circuit Design SMD1x1=1 DIEAS
Display Color STN Blue Monochrome with White Backlight
Product Features
  • STN blue negative transmissive display, clear monochrome display effect with white backlight
  • Professional ST7066 driver IC, stable driving performance and strong anti-interference ability
  • 5.0V standard drive voltage, compatible with mainstream industrial power supply systems
  • 1/16 Duty & 1/5 Bias design, low power consumption and long-term stable operation
  • 6 o'clock viewing angle, optimal visual experience for industrial equipment operation
  • 20MA white backlight, uniform luminescence and high brightness for dark environment use
  • Wide temperature adaptation (-20~70℃ working), suitable for harsh industrial working environments
  • Standard 14PIN pinout (GND/VDD/VO/RS/RW/E/DB0-DB7), easy to connect and integrate
  • Durable PCB + iron frame structure, strong mechanical stability and long service life
  • Broad storage temperature range (-30~80℃), convenient for transportation and storage
  • SMD circuit design, compact structure and easy for embedded installation
Product Applications
  • Industrial control equipment and industrial operation display panels
  • Electronic measuring instruments, digital meters and precision testing equipment
  • Embedded control systems and smart industrial terminal devices
  • Small electronic equipment, portable test instruments and handheld terminals
  • Automotive auxiliary electronic devices and on-board small display modules
  • Smart home control panels and low-power intelligent display equipment
  • Communication terminal accessories and industrial sensor display modules
  • Various small digital display equipment with monochrome display demands
