1.05 120×240 IPS Screen 4-Pin SPI 400cd/m² for Smart Devices
1.05 120×240 IPS Screen 4-Pin SPI 400cd/m² for Smart Devices
1.05 120×240 IPS Screen 4-Pin SPI 400cd/m² for Smart Devices
1.05 120×240 IPS Screen 4-Pin SPI 400cd/m² for Smart Devices
1.05 120×240 IPS Screen 4-Pin SPI 400cd/m² for Smart Devices
1.05 120×240 IPS Screen 4-Pin SPI 400cd/m² for Smart Devices
Specifications
Brand Name :
YZY
Model Number :
NT105HC-H13-01
Certification :
CE, ROHS
Place of Origin :
Guangdong, China
MOQ :
500 pieces
Price :
$1.69~2.99/pieces
Payment Terms :
T/T
Supply Ability :
10000Pieces
Delivery Time :
14-60 days
Packaging Details :
15*15*8
Description
1.05 Inch IPS TFT LCD Display Module 120x240 4-Wire SPI

This 1.05 inch IPS TFT LCD display module offers 120*240 resolution, 4-Wire SPI interface, 400cd/m² high brightness and full viewing angle. Designed with normally black mode, 262K colors and wide temperature range, it delivers stable performance for wearables, handheld devices, industrial controls, smart home and portable electronics.

Key Specifications
Product 1.05 inch IPS TFT LCD Module Display Type IPS TFT, Normally Black
Resolution 120(RGB)*240(V) Pixels Display Colors 262K Colors
Brightness 400 cd/m² (Typical) Outline Dimensions 14.25*28.60*1.56 mm
Viewing Direction Full Viewing Angle (ALL) Active Area 11.88*23.76 mm
Interface 4-Wire SPI Operating Temperature -20℃ to +70℃
Driver IC GC9A01 Storage Temperature -30℃ to +80℃
Pixel Pitch 0.099*0.099 mm Contrast Ratio 800:1 (Typical)
Response Time 30 ms (Typical) Touch Panel Without Touch
Supply Voltage 2.5V~3.3V (Typ 2.8V) Compliance RoHS Compliant
Product Highlights: 1.05 inch IPS TFT LCD, 120*240 resolution, 4-Wire SPI interface, 400cd/m² high brightness, full viewing angle, 262K colors, wide temperature -20℃~70℃, compact size, RoHS compliant, ideal for wearable & portable devices
Technical Features
  • 1.05-inch compact IPS TFT LCD with 120*240 high resolution
  • Full viewing angle (ALL directions) for clear image from any angle
  • 400cd/m² high brightness for excellent readability in various environments
  • 4-Wire SPI interface for stable communication and easy control
  • 262K full color display with RGB vertical stripe arrangement
  • Normally black display mode with high contrast up to 800:1
  • Wide operating temperature range for industrial & outdoor applications
  • Ultra-thin module design for easy integration into small devices
  • RoHS compliant to meet international environmental standards
  • Long-term reliability with strict reliability testing passed
Electrical Specifications

Analog supply voltage VCC: 2.5V ~ 3.3V (Typical 2.8V)
Backlight forward voltage: 2.9V ~ 3.1V (Typical 3.0V)
Backlight forward current: 20mA (Typical)
Input high voltage: ≥0.7*IOVCC; Input low voltage: ≤0.3*IOVCC
Operating current: Stable within rated range for long-term use
ESD protection design to prevent damage from static electricity

Pin Definition
PIN Symbol Description
1 NC No connect
2 NC No connect
3 SDA SPI interface input/output pin
4 SCL Serial interface clock
5 D/C Display data/command selection pin
6 RESX
This signal will reset the device and it must be applied to properly initialize the chip. -Signal is active low
7 CSX Chip selection pin, Low enable. Highdisable.
8 GND Ground
9 NC No connect
10 VCC
Power supply for Analog
11 LED-K Backlight cathode
12 LED-A Backlight anode
13 GND Ground
Application Scenarios
  • Smart wearable devices: smart watches, wristbands, fitness trackers
  • Handheld industrial instruments, measuring meters and testing equipment
  • Portable electronics: voice recorders, small smart gadgets, beauty devices
  • IoT terminals and smart home sensor display modules
  • Medical: portable health monitors and small diagnostic devices
  • Industrial control: small HMI, equipment status indicators
  • Consumer electronics: electronic toys, pedometers, small home appliances
Customization Options
  • FPC Design: Custom FPC length, pin layout and interface direction
  • Brightness Customization: Adjust brightness level for special environments
  • Interface Configuration: SPI timing and driver code adaptation
  • Mechanical Adjustment: Outline and installation structure customization
  • Packaging Service: Anti-static vacuum packaging with desiccant
  • Mass Production Support: Flexible MOQ and lead time for bulk orders
Handling Notes
1. Electrostatic Protection: Use anti-static wrist straps and grounded tools. Avoid dry environment (RH 50%-60% recommended). Do not touch pins or FPC directly with hands.
2. Surface Care: The polarizer is fragile. Use soft cloth with IPA to clean; do not use dry cloth, water or chemical solvents.
3. Storage: Store in dark, anti-static container at 23±5℃, humidity ≤65%RH. Avoid strong light, high temperature and dust.
4. Soldering: Temperature 320~350℃, time ≤10s. Do not stay too long on FPC to avoid burning.
5. Mechanical Safety: Do not press, drop or bend the module. Avoid external force on the display surface.
Product Image
1.05
Application Scenarios
1.05
Our Factory
1.05
Product Packaging
1.05 1.05
Shipment & Payment
1.05
Frequently Asked Questions
How do you control product quality?

Each product undergoes strict testing before shipping following MIL-STD-105E sampling plan and multiple reliability tests including high/low temperature storage, high temperature & high humidity operation and image sticking test.

Do you supply samples?

Yes, we provide samples for customer evaluation and functional testing.

What is the delivery time?

Typically 7 working days after payment confirmation for standard orders. Custom orders may require additional lead time.

What is the minimum order quantity?

200 piece minimum order quantity for sample orders, with flexible MOQ for bulk production.

What if we receive missing or defective items?

Contact us immediately for investigation and prompt resolution. We offer replacement or refund for confirmed quality issues.

What are your main products?

Comprehensive range including LCD modules, LCM, touch modules, LCD panels, FPC boards and optoelectronic materials for industrial, medical, automotive, smart home and consumer electronics applications.

What payment methods do you accept?

We accept T/T (Telegraphic Transfer) payments, Western Union, and PayPal for small orders.

What shipping methods do you offer?

DHL, FedEx, UPS and China Post shipping services available. Express delivery is available for urgent orders.
