Specifications
Brand Name :
YUTAI
Model Number :
YT-890
Certification :
CE
Place of Origin :
China
MOQ :
1Set
Price :
$2000
Payment Terms :
L/C, T/T
Supply Ability :
100sets/month
Delivery Time :
7-15 working days
Packaging Details :
Standard export wooden case
Voltage :
220v/50hz
Power :
1kw
Temperature :
100°c-200°c
Output :
4000-4500 pairs / 8 hours
Machine size :
1120mm*580mm*1450mm
Description

1. Automatic label transfer machine is widely used in sports shoe insole/shoe tongue thermal transferhot stamping machine, leather branding processing, etc.
2. This machine Control system adopts PLC and touch screen temperature control system adopts PID temperature module to connect with touch screen, no need to install temperature control.The temperature control is accurate, and the temperature difference is controlled at about 1℃.

3. Unique false ironing function. In the case of no material, the pressing die will automatically stop pressing and the ironing operation is stable. It adopts Japanese stepping motor, circle label, and label delivery are stable and reliable.
4. The unwinding adopts the principle of reverse rotation of the motor to make the standard belt always tighten, to reduce the error during standard operation, and the power frequency can be adjusted at will without noise.
5. This machine has two working modes, hot stamping and hot stamping can be switched arbitrarily, one machine has multiple functions.
