K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E
K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E
K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E
K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E
K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E
K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E
K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E
K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E
Specifications
Brand Name :
VOLVO
Model Number :
K3V280SH180L-0E53-VB
Certification :
ISO
Place of Origin :
Japan
MOQ :
1 set
Payment Terms :
T/T, Western Union
Supply Ability :
1000sets per month
Delivery Time :
1-3 days
Packaging Details :
Wooden case
Product name :
VOLVO Hydraulic Main Pump
Type :
Hydraulic Piston Pump Assy
Model :
K3V280SH180L-0E53-VB
Part number :
14670155
Application :
VOLVO Excavator
Application model :
EC950E
Material :
Casting Iron & Steel
Condition :
100% Original Brand New
Description

K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E

Product Details

K3V280SH180L-0E53-VB VOLVO Hydraulic Main Pump 14670155 For EC950E
Product Name:
Hydraulic pump
Model Number:
K3V280SH180L-0E53-VB
Brand Name: VOLVO Place Of Origin: Japan
Condition:
Original Brand New
Delivery:
Within 1-3 days
Inventory:
In stock
 Material: Iron & Steel
Packing:
Wooden Case
Payment Term:
T/T, Western Union
Application: VOLVO Excavator Applicable model: VOLVO EC950E
Weight: 180KGS Dimension(L*W*H): 85X45X64CM
Warranty: 6 months After Warranty Service: Online support
Guarantee: We will check the pumps and send detail pictures to buyer to confirm before shipping.

K3V280SH Hydraulic Pump Spare Parts

We Provide New Kawasaki K3V280 Piston Pump Rotary Group, Replacement And Spare Parts, 100% Compatible With Original Kawasaki, Good Quality Piston Pump Parts And More Cost Effective Price. Spare parts include: Rotary Group, Drive Shaft, Support, Swash Plate, Yoke, Thrust Plate, Shoe Plate, Retainer Plate, Set Plate, Ball Guide, Piston Shoe, Pistons, Cylinder Block, Barrel, Valve Plate, Port Plate and other parts. Yunki is your aftermarket solutions partner for Kawasaki replacement piston pump parts. Precision piston pump parts can totally interchange with original Kawasaki, same specification and duration.

Item No. Name & Description QTY (pcs) Remark
1 K3V280SH DRIVE SHAFT 1 SHAFT
2 K3V280SH SUPPORT 1
3 K3V280SH SWASH PLATE 1 YOKE
4 K3V280SH THRUST PLATE 1 SHOE PLATE
5 K3V280SH RETAINER PLATE 1 SET PLATE
6 K3V280SH BALL GUIDE 1
7 K3V280SH COIL SPRING 1
8 K3V280SH PISTON SHOE 9 PISTONS
9 K3V280SH WASHER 1
10 K3V280SH CYLINDER BLOCK 1 BARREL
11 K3V280SH VALVE PLATE 1 PORT PLATE

Features

K3V series: K3V63, K3V112, K3V140, K3V180, K3V280

1. With new technology the K3V series has realized higher power density.

2. K3V series can cope with enlargement of displacement despite the same installation dimensions and regulator variations as K3V’s.

3. K3V series pumps have realized higher reliability and long life so as to meet requirement of larger torque.

Model K3V63 K3V112 K3V140 K3V180 K3V280
Displacement /cm3 63 112 140 180 280
Pressure MPa
(kgf/cm2)
 Rated 34.3 (350)
Peak 39.2 (400)
Speed
/min-1
 Max.for self priming 2,650 2,360 2,150 1,950 1,600
Max 3,250 2,700 2,500 2,300 2,300

VOLVO Excavator Hydraulic Pump Models

VOLVO 14508164 1142-06230 K3V63DT-1RCR-9N03-1
14508164 14500380 K3V63DT-1R0R-9NOT
14510170 14508164 K3V63DT-1Y0R-9NOT
14520050 14512271 K3V63DT-1ZDR-9N0T-ZV
14520750 14516405 K3V112DT-1RCR-9N09
14526609 14522561 K3V112DT-1XER-9N24-2
14531300 14524052 K3V112DT-1XDR-9N24-ZV
14531591 14526609 K3V112DT-1XER-9N2A-2
14531594 14531412 K3V140DT-1RCR-9N19
14533644 14531857 K3V140DT-1JER-9N04-1
14612484 14549798 K3V180DT-1PCR-9N46
14618624 14612484 K3V180DTH-1POR-9N0S
1040-74390 14618624 K3V180DT-1PER-9N56
1042-02191A 14621492 K3V180DTH-1POR-9NOB
1042-07700 14623786 K3V180DT-152R-9N05-AHV
1142-00010 7220-00601 K5V80DT-1 PDR-9N0Y-ZV
1142-00530 1142-00900 K5V80DT-1PDR-9N0J-ZV
14574463 14676708 K5V80DT-1V9L-1E01-V
1142-00660 1142-05460 K5V200DTP180R-9N8X-V

We offer wide range of hydraulic pumps that can suit to excavator such as Komatsu, Caterpillar, Hitachi, Kobelco, Mitsubishi, Hyundai, Volvo.

All of our Hydraulic Pumps are packed well in wooden case.
