Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)
Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)
Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)
Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)
Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)
Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)
Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)
Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)
Specifications
Brand Name :
GTLCON
Model Number :
2-14 Pin Industrial Connector
Certification :
CE、TUV、UL、RoHS
Place of Origin :
China
MOQ :
50
Price :
Negotiable
Payment Terms :
,T/T,Western Union,D/P,D/A,L/C,MoneyGram
Supply Ability :
10000/day
Delivery Time :
Sample: 1-3 days; Small order: 3-10 days; Bulk order: 10-18 days
Packaging Details :
High quality export packaging
Name :
2-14 Pin Industrial Connector
Hardware materials :
Copper/Nickel-plated
Housing Material :
PA66
Mechanical life :
2000 times
Operating temperature :
-20℃～120℃
hardware :
Purple copper
Description

Product advantages


☑ Versatile Applications
☑ Easy Installation and Removal
☑ Low Resistance and High Conductivity, Effectively Minimizing Energy Loss
☑ Features High-Grade Waterproofing
☑ Resilient to Vibration, Temperature Fluctuations, and Humid Environments


Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)

Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)

Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)

Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)

Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)

Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)

Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)

Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)




Industrial Waterproof Connectors
Product Features
This industrial connector interface features a flip-cover protection design. The housing is constructed from engineering-grade plastic and incorporates a threaded locking mechanism; the interior reveals multiple sets of metal pins, supporting multi-core configurations to accommodate diverse power and signal transmission requirements.
Protective Design
Boasting a high protection rating of IP67 or higher, the connector utilizes sealing rings and a threaded locking structure to achieve effective waterproofing, dustproofing, and oil resistance. Models equipped with a flip-cover provide protection for the interface even when not mated, further enhancing the product's adaptability to various environmental conditions.

Product Selling Points
Strong Environmental Adaptability
Designed with a high protection rating, it withstands harsh environments—including outdoor rain, submersion, dust, and oil contamination—and handles complex climatic conditions found in industrial settings, such as extreme temperatures and UV exposure, ensuring a long service life.
Stable and Reliable Connection
The threaded locking mating design ensures a firm connection that resists loosening, while maintaining moderate insertion and extraction forces. This guarantees the long-term stability of power and signal transmission, minimizing faults caused by loose connections.
Convenient and Efficient Operation
Mating and unmating can be accomplished without the need for complex tools. Select models feature a "foolproof" (anti-misinsertion) design to prevent interface damage caused by incorrect mating. Models equipped with a mounting base allow for rapid, fixed installation, significantly boosting installation and maintenance efficiency.
Wide Range of Applications
Supporting multi-core configurations and various specifications, these connectors accommodate equipment with different cable diameters and diverse power/signal transmission needs. Applicable scenarios span numerous fields, including industrial automation, engineering machinery, marine vessels, new energy systems, and outdoor lighting.
Applicable Uses
Industrial Environments
In settings such as industrial automation production lines, engineering machinery, and shipbuilding, these connectors provide stable and reliable power and signal transmission links for equipment, enabling them to withstand complex working environments and ensuring the continuity of production processes.
Outdoor Environments
Suitable for power connections in outdoor LED lighting fixtures, landscape lighting systems, and outdoor billboards, they also facilitate power supply and signal transmission for outdoor surveillance equipment, effectively resisting the corrosive effects of harsh outdoor weather.
New Energy Environments
In applications such as new energy vehicle charging stations, photovoltaic power plants, and energy storage systems, these connectors provide safe and reliable power transmission links for equipment, meeting the specific requirements of the new energy sector. Temporary Power Connection
Providing temporary power connections suitable for large-scale events, outdoor construction sites, and similar scenarios. This solution enables rapid electrical linking between equipment, ensuring that all temporary power requirements are met.
If you would like to learn more about the specific parameters of particular models or their applicable use cases, please feel free to reach out at any time!



OUR CUSTOMERS


Industrial Plugs (16A/32A) & Flush-Mount Waterproof Industrial Sockets — 3-Phase 4-Wire / Aviation-Style (3-Pin, 4-Pin, 5-Pin)


FAQ


‌

1. Q: What types of waterproof connectors do you have?
A: We have 17 series connectors and produce more than 5000 connectors and their cable assemblies. Most of our connectors are customized. We specialize in EV connectors, lithium battery connectors, energy storage connectors, solar photovoltaic connectors, LED waterproof connectors, assembled waterproof connectors

2. Q: How to buy your products?
A: You need to do the following:
* Confirm the rated current and number of contacts
* Confirm the assembly style
* Confirm the cable wire gauge
* Confirm the cable length and shipping method

3. Q: How to contact you?
A: Please email us, we have been in this industry for more than 19 years, so we can grasp your problem and solve it in a short time. If you have any questions, please feel free to let us know.
