K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel
K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel
K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel
K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel
K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel
K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel
K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel
K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel
Specifications
Brand Name :
YDPB
Model Number :
K32013XP0
Certification :
ISO
Place of Origin :
Luoyang，China
MOQ :
1PCS
Price :
1$
Payment Terms :
Western Union, T/T, L/C
Packaging Details :
standard export packaging
Material :
GCR15
Precision :
P6,P5
Structure :
Custom made available
OEM :
available
Description

Description

YDPB is professional on the bearings inlcude Kaydon standard think section bearings ,THK IKO

standard crossed roller bearings,INA standard Rotary Table bearings ,and also with many stock ones

flexible deep groove ball bearings used for harmonic drive, custom made bearings avaible.

Kaydon thin-section bearings Structure
Open type deep groove ball bearing
Open type angular contact bearing
Open type four point contact bearing
Sealed type deep groove ball bearing
Sealed four point contact ball bearing
Feature
1. compact structure, light weight, low vibration and friction
2. space and cost saving
3. best quality, long life

Parameters and related photoes for thin section ball bearings YDPB produce

13mm Series
Model Dimension Load capacity Weight
Basic Size Side wall size Radial Axial Torque N-m
id OD L1 L2 Static Dynamic Static Dynamic Static Dynamic
K32013XP0 320 346 329.7 336.3 5042 2419 12605 3966 8232 2963 0.97
K34013XP0 340 366 349.7 356.3 5365 2508 13412 4133 9286 3257 1.02
K36013XP0 360 386 369.7 376.3 5688 2594 14220 4298 10403 3560 1.08

K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless SteelK32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel

K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel

K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel

Application

Transport

K32013XP0 Thin Section Bearings For Indexing tables Brass Cage Custom Made Bearings Stainless Steel

Drawings,price and other information needed ,pls send us email ydbearing@foxmail.com or call us directly .
