Specifications
Warranty :
1 year
Customized support :
OEM, ODM
Place of Origin :
Zhejiang, China
Brand Name :
YIXIST
Model Number :
YSM-8102-06
Size :
140mm x 110mm x 46mm
Weight :
0.7 Kg, 0.7Kg
Wavelength Range :
200nm - 1100nm
Model :
YSM-8102-06
Dimension :
140mm * 110mm * 46mm
Optical resolution :
Determined by the grating and slit
Fiber connector :
SMA905
Detector :
Hamamatsu S13496 Line array CMOS
Pixel :
4096 pixels Pixel size 7um*200um
Signal to noise ratio :
600:1 at full signal
Dynamic range (Single) :
10000:1
Price :
$3,687.00/pieces >=1 pieces
MOQ :
1 unit
Description
Promotion High Accuracy Wide Frequency Range Spectrum Analyzer for Usb2.0 Data Transfer
PRODUCT OVERVIEW
YSM-8102-06 series high-resolution spectrometers adopt Hamamatsu 4096-pixel S13496 CMOS detector, whose pixel resolution has increased by one time compared with an S11639 detector. It vastly improves the accuracy of spectrometers and is ideal for LIBS and other laser spectral measurements.

Feature

Up to 4096 pixels resolution. Cross-symmetric C-T optical structure. Filters eliminate secondary and advanced diffractions . Customizable wavelength range and optical resolution. USB2.0 data transfer and power supply. Support USB2.0, RS232, RS485. Support OEM and in-depth customization.

Application

Laser central wavelength, FWHM and stability measurement
LIBS multi-channel monitoring
MODEL LIST
Promotion High Accuracy Wide Frequency Range Spectrum Analyzer for Usb2.0 Data Transfer
PRODUCT SPECIFICATIONS
Model
YSM-8102-06
Detector
Hamamatsu S13496
Line array CMOS 4096 pixels
Pixel size 7µm×200µm
Wavelength response range 200nm-1100nm
Dimension
140mm×110mm×46mm
Wavelength Range
Determined by the grating
Optical Resolution
Determined by the grating and slit
A/D
16bit
Integration Time
0.5ms-65s
Dynamic Range
10000:1
Signal to noise ratio
600:1 at full signal
Linearity
>99%
Trigger Mode
Software, Hardware, Synchronous
Power Consumption
5VDC,300mA
Fiber Connector
SMA905
Operating Temperature
5℃-35℃ (recommended temperature 25℃)
Communication Interface
USB2.0, RS232
Operating System
Win XP, Win 7, Win 8, Win10
Power Supply
USB
TYPICAL TESTING
Promotion High Accuracy Wide Frequency Range Spectrum Analyzer for Usb2.0 Data Transfer
Promotion High Accuracy Wide Frequency Range Spectrum Analyzer for Usb2.0 Data Transfer
RELATED ACCESSORIES
Promotion High Accuracy Wide Frequency Range Spectrum Analyzer for Usb2.0 Data Transfer
Fiber
Promotion High Accuracy Wide Frequency Range Spectrum Analyzer for Usb2.0 Data Transfer
Light Source
Promotion High Accuracy Wide Frequency Range Spectrum Analyzer for Usb2.0 Data Transfer
Sample Holder
COMPANY PROFILE
Promotion High Accuracy Wide Frequency Range Spectrum Analyzer for Usb2.0 Data Transfer

YIXI Smart Technology (YIXIST) Co., Ltd.
YIXIST is an innovative technology enterprise based on advanced optical measurement technology, which integrates research, development, manufacturing, and sales of digital and networked intelligent equipment.It is a vigorous and enterprising high-tech corporation founded by professors and engineers.

"Professionalism, concentration, and integrity" is our business philosophy. The company is determined to become the best supplier and advanced technology provider in the intelligent equipment manufacturing industry to create the greatest value for customers continuously.YIXIST can independently manufacture complete sets of optical measuring equipment and provide comprehensive solutions for digital physics experiments development.
