| Image Sensor | Sensor | 1/2.8″ Sony Sensor |
| Signal System | PAL/NTSC | |
| Minimum Scene illumination | 0.1Lux at F.6 | |
| White Balance | AUTO/Manual | |
| Gain Control | AUTO | |
| Back-light compensation | ON/OFF | |
| S/N Ratio | >50db | |
| Lens | Lens | f=4.7-47mm |
| Iris | AUTO/Manual | |
| Zoom | 10x autofocus lens | |
| Horizontal Angle of view | 58 degree | |
| Video Output | USB2.0 Interface | |
| Video format | MJPG/1080P29, 720P@30 | |
| Control Decoder | EIA/RS-485, USB | |
| Communication | EIA/RS-232(Bidirectional) | |
| PTZ Control Protocol | VISCA,PELCO-D | |
| Baud Rate | 9600/38400bps | |
| Patrol tours | 4 | |
| Preset | 64 | |
| Save status after Power off | Support | |
| Speed Matching Function | Support | |
| Image Auto Flip | Support | |
| Pan Speed | 0-280 degrees/s | |
| Tilt Speed | 0-100 degrees/s | |
| Pan Rotation Angle | 355 degrees | |
| Tilt Rotation Angle | + 90 degrees, - 45 degree | |
| Auto Pan Scan | Support | |
| Boundary Scan | 0-359degree(Programmable) | |
| Remoter Control | IR Wireless remote control P/T/Z | |
| Power | DC12V ±10% 1.2A | |
| Operation Temperature | 0°C~50°C | |
| Environmental humidity | 0-95%RH(non-condensation) | |
| Length X width X high | 124x120x145mm/220x175x220mm(NET/PACKAGE) | |
| Weight | 640g/1100g(NET/PACKAGE) | |
