48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
Specifications
Model Number :
MP-WALL-48V
Brand Name :
MASTPOWER
Place of Origin :
Guangdong, China
Packaging Details :
Strong Carton Package
Supply Ability :
100000 Piece/Pieces per Month
Price :
$678.00/pieces 1-49 pieces
Battery Type :
Lithium Ion, LiFePO4
Product Name :
Home Wall-Mounted Energy Storage Battery
Battery type :
LiFePO4
Factory Voltage :
51V-53V(40-60%)
Application :
Solar energy storage system
Voltage at end of Discharge :
40-44V
OEM/ODM :
YES
Charging Voltage :
56-58V
Limiting current :
20A
Weight :
107Kg
Capacity :
10KWh
Port :
Shenzhen
Description
Product Description
Model
Lithium Battery Module
Power Wall 48V 100AH/150AH/200AH
Voltage
48V 50AH
48V 100Ah
48V 150Ah
48V 200Ah
Display
LCD Optional
LCD
BMS
Built-in BMS
Cycles LiFe
6000
Warranty
5Years
Communication
CAN/RS485
Operation Temperature
Discharge: -20℃-55℃(pack internal temperature )
Factory voltage Range
50V～53V
Charge Voltage
58.4V
Charge Mode
0.33C to 58.4V, then 58.4V,charge current to 0.02C (CC/CV)
Max Charge Current
50A
100A
100A
100A
Discharge Temperature
-20 ℃ to 55℃ (-4F to 131F) @60±25% Relative Humidity
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh

Battery Management System Specification

BMS function introduction The BMS have all functions which are : Overcharge detection function Over discharge detection function Over current detection function Short detection function Temperature detection function Balance function Communicate function Alarm function Total capacity function Storage history function
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
48v 51.2v 50ah 100ah 200ah Lithium Ion House Battery With Smart BMS Powerwall 10kw 10kwh
