GYXTW OM2 2-24 Core Multimode Fiber Optic Cable – Outdoor Central Loose Tube Armored Cable for Aerial and Duct Installation
GYXTW OM2 2-24 Core Multimode Fiber Optic Cable – Outdoor Central Loose Tube Armored Cable for Aerial and Duct Installation
GYXTW OM2 2-24 Core Multimode Fiber Optic Cable – Outdoor Central Loose Tube Armored Cable for Aerial and Duct Installation
GYXTW OM2 2-24 Core Multimode Fiber Optic Cable – Outdoor Central Loose Tube Armored Cable for Aerial and Duct Installation
GYXTW OM2 2-24 Core Multimode Fiber Optic Cable – Outdoor Central Loose Tube Armored Cable for Aerial and Duct Installation
GYXTW OM2 2-24 Core Multimode Fiber Optic Cable – Outdoor Central Loose Tube Armored Cable for Aerial and Duct Installation
Specifications
Brand Name :
Ebocom
Model Number :
GYXTW-OM2
Certification :
ISO
Place of Origin :
China
MOQ :
1000 M
Payment Terms :
L/C, T/T
Supply Ability :
200KM per Day
Delivery Time :
3-10 days
Packaging Details :
Plywood Drum or Custimized
Price :
0.02 USD per Meter
Application :
Aerial,Duct
Fiber type :
50/125, OM2
Fiber count :
2/4/6/8/12/24 Core
Jacket :
PE
Length :
1 km 2km 3km per drum
Oem :
Available
Description

Description

GYXTW OM2 fiber optic cable is a central loose tube outdoor multimode solution, built to perform reliably in short- and mid-distance communication networks. It combines proven structure with field-ready protection, making it a top choice for campus wiring, factory zones, and surveillance networks.

This cable features OM2 (50/125μm) multimode fibers in a gel-filled PBT tube, providing excellent environmental sealing and mechanical buffering. Two steel wires ensure tensile support, while a corrugated steel tape armor layer defends against crushing, bending, and rodent damage. The HDPE outer jacket resists UV and water, allowing flexible deployment in ducts, buried routes, or on poles.

Key Advantages

  • OM2 50/125μm multi mode fibers – Ideal for 100Mb–1Gb Ethernet up to 550m

  • Central loose tube structure – Compact and efficient for 2–24 fiber counts

  • No metal in fiber core – Immunity to EMI, suitable for light industrial use

  • Corrugated steel armor – Adds durability against harsh ground pressure

  • Dual steel wire reinforcements – Enables mid-span aerial use without sag

  • Smooth installation – Compatible with blowing, pulling, or lashing

Typical Use Cases

  • CCTV backbone wiring for residential or commercial zones

  • Fiber runs between buildings or data points within a complex

  • Medium-range outdoor connections for schools, hospitals, or logistics sites

  • Outdoor patching to cabinets, shelters, or remote equipment

  • Network extension for industrial parks and municipal infrastructure

Product Specifications

Item Description
Fiber Type OM2 Multimode (50/125μm)
Fiber Count 2 to 24 cores
Tube Material PBT, filled with gel
Strength Members 2 × Steel Wire (0.6mm–1.2mm)
Armoring Steel Tape
Outer Jacket PE (UV and abrasion resistant)
Nominal Diameter 6.0–10.0mm (varies by core count)
Short-Term Tensile Load ≥1500N
Crush Resistance ≥1000N/100mm
Operating Temperature −40°C to +70°C
Max Distance (1Gbps) 550m (OM2 standard)
Installation Options Aerial / Duct / Direct Burial
Certifications IEC 60794, ISO/IEC 11801 OM2
