GJFJH Indoor Optic Cable 48 cores MM OM1 OM2 OM3 OM4 OM5 Yellow Green Orange Color Distribution communication
GJFJH Indoor Optic Cable 48 cores MM OM1 OM2 OM3 OM4 OM5 Yellow Green Orange Color Distribution communication
GJFJH Indoor Optic Cable 48 cores MM OM1 OM2 OM3 OM4 OM5 Yellow Green Orange Color Distribution communication
GJFJH Indoor Optic Cable 48 cores MM OM1 OM2 OM3 OM4 OM5 Yellow Green Orange Color Distribution communication
Specifications
Brand Name :
EBOCOM
Model Number :
GJFJV-48B1
Certification :
ISO TLC
Place of Origin :
Shandong，China
MOQ :
2000M
Price :
EXW ≥2000m $0.2/M ≥5000m $0.19/M
Payment Terms :
T/T
Supply Ability :
5000KMS/day
Delivery Time :
5-8 day
Packaging Details :
1. Iron-wooden drum or non-fumigation wooden drum,normal wooden drum. 2. Drum size can be designed,details will calculation for suitable for containers.
Product Name :
GJFJV/GJFJH
Jacket :
PVC /LSZH
Strength Member :
Aramid yarn
Fiber :
Single mode/multi mode
Brand :
Ebocom or OEM
Description

Description

The GJFJH cable is a high-performance tight-buffered fiber optic cable primarily designed for indoor and building environments. It features a round, flexible design built with multiple tight-buffered fibers wrapped in aramid yarn and an LSZH (Low Smoke Zero Halogen) jacket, providing excellent tensile strength, flame retardancy, and easy installation

Features

Flexibility & Bend Radius: The tight structure makes it highly flexible and soft, allowing it to navigate tight corners and spaces in buildings with a superior bend radius.Easy Stripping & Splicing: The tight buffer ensures easy stripping, simplifying on-site termination and splicing.Flame Retardant: LSZH jacketing guarantees safety in compliance with fire regulations for indoor environments.

GJFJH Indoor Optic Cable 48 cores MM OM1 OM2 OM3 OM4 OM5 Yellow Green Orange Color Distribution communicationGJFJH Indoor Optic Cable 48 cores MM OM1 OM2 OM3 OM4 OM5 Yellow Green Orange Color Distribution communication

Applications

FTTX & LAN Networks: Used for vertical and horizontal cabling within high-rise buildings, data centers, and Local Area Networks (LAN).Patch Cords & Pigtails: Ideal for manufacturing fiber optic patch cables and pigtails to connect active devices in racks.Equipment Interconnection: Acts as a backbone or transition cable bridging indoor communication rooms and equipment interconnectivity

Mechanical Specifications

Cable Model Outer Diameter

(mm)

 Weight

(kg/km)

 Tensile Strength(N) Crush Resistance(N/100mm) Bending Radius Jacket Thickness(mm)
Long term Short term Long term Short term Dynamic Static
GJFJV-2F 3.6±0.2 12.5 180 440 300 1000 20D 10D 0.45±0.05
GJFJV-4F 4.7±0.2 17.6 180 440 300 1000 20D 10D 0.8±0.1
GJFJV-6F 5.2±0.2 22.8 180 440 300 1000 20D 10D 0.9±0.1
GJFJV-8F 5.8±0.2 26.7 180 440 300 1000 20D 10D 0.9±0.1
GJFJV-12F 6.3±0.2 32.7 180 440 300 1000 20D 10D 0.9±0.1
GJFJV-24F 8.0±0.2 53 200 660 300 1000 20D 10D 1.0±0.1
